Based in Kolkata, India, Neil Metals is a well-known producer and supplier of Grade 12 Titanium Bars and Rods, providing premium goods suited to exacting industrial uses. Neil Metals is well-known for its dedication to accuracy, robustness, and performance. It produces Grade 12 titanium bars with exceptional mechanical strength and resistance to corrosion. The industries of power generation, marine, and chemical processing all make extensive use of these bars and rods. Neil Metals guarantees that every Titanium Grade 12 product satisfies international standards through sophisticated production capabilities and strict quality control, offering dependable solutions to customers throughout India and international markets with prompt and effective deliveries.
Compared to commercially pure titanium grades, Titanium Grade 12 is a titanium alloy that has been slightly enhanced in strength and corrosion resistance by the addition of 0.8% nickel and 0.3% molybdenum. It usually has an elongation of roughly 18%, a yield strength of 345 MPa, and a tensile strength of 483 MPa. Particularly in mildly reducing and oxidising conditions, this alloy provides exceptional resistance to pitting and crevice corrosion. Titanium Grade 12 is a versatile material for high-pressure and high-temperature industrial applications because it also retains good weldability, toughness, and thermal stability.
| Standards : | ASTM B348, B863 / ASME SB348, SB863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 12 | 3.7105 | R53400 |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 9 | .08 max | .03 max | .25 max | .015 max | Bal | 0.30 max | – | .12 – .25 |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade 12 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Density | Melting Range | Modulus of Elasticity (Tension) | Specific Heat | Mean Coefficient of Expansion | Thermal conductivity | Electrical Resistivity |
| kg/m3 | °C | GPa | J/kg. °C | x10 -6 / °C | W / m. °C | micro-ohm.m |
| 4,507 | 1668± 10 | 103 | 519 | 8.41 | 11.4 | 0.420 |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Grade 12 Titanium Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Titanium Grade 12 offers excellent resistance to corrosion, especially in oxidizing and mildly reducing environments, and is highly durable in seawater and chemical processing conditions.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@neilmetals.co.in
Yes, Titanium Grade 12 exhibits remarkable high-temperature resistance, making it suitable for use in power generation and industrial processes that involve elevated temperatures.
Because of their exceptional resistance to corrosion, titanium grade 12 bars and rods are widely used in chemical processing facilities, particularly in systems that handle acids, chlorides, and wet gases. They are perfect for piping systems exposed to harsh conditions, reactor vessels, evaporators, and heat exchangers. Grade 12 titanium is the material of choice in the marine industry for ship components, desalination plants, and offshore applications. It is also used for boiler and condenser systems in the power generation industry. They are essential in vital, long-lasting industrial infrastructures due to their mechanical stability and dependability in corrosive environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Neil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kolkata, India
