Based in Kolkata, India, Neil Metals is a well-known producer and supplier of high-performance titanium grade 11 forgings, offering precisely engineered goods to satisfy a range of industrial needs. Titanium Gr 11 is a popular material for harsh environments because of its strong mechanical qualities and remarkable resistance to corrosion. Neil Metals uses cutting-edge forging techniques and complies with international standards to guarantee excellent quality. The business serves sectors like energy, aerospace, marine, and chemical processing. Neil Metals offers Titanium Gr 11 forgings that combine strength and stability for long-term performance, with an emphasis on dependability, durability, and customer satisfaction.
Titanium Grade 11 is a commercially available titanium alloy that has been enhanced with 0.12% to 0.25% palladium. This greatly increases the alloy’s resistance to corrosion, especially in environments that are acidic and reducing. It has outstanding ductility, weldability, and formability. Tensile strength of about 345 MPa, yield strength of about 275 MPa, and elongation of about 24% are typical mechanical characteristics. Because of these qualities, titanium Gr 11 can be fabricated and used in harsh chemical and marine environments without losing its exceptional structural integrity or ability to crack under stress corrosion.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 11 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | 12 – .25 |
| Grade | Tensile Strength min | Yield Strength (0.2 % Offset) | Elongation | Reduction of Area | ||
| ksi | Mpa | ksi | Mpa | min % | min % | |
| 11 | 35 | 240 | 25 | 170 | 24 | 30 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 11 | 3.7225 | R52550 |
Yes, Titanium Gr 11 forgings are highly corrosion-resistant, especially to oxidizing environments and seawater. This makes them ideal for applications in industries like aerospace, marine, and chemical processing, ensuring long-lasting durability.
Titanium Gr 11 forgings are commonly used in industries such as aerospace, marine, chemical processing, medical, and power generation. Their strength, corrosion resistance, and high-performance capabilities make them ideal for demanding applications.
Yes, Titanium Gr 11 forgings can be customized for specific applications, offering tailored sizes, shapes, and properties to meet unique industry requirements, ensuring optimal performance and reliability in demanding environments.
Chemical processing facilities frequently use titanium grade 11 forgings, especially for the production of chlorate and hypochlorite, where exceptional corrosion resistance is crucial. Heat exchangers, reactors, pressure vessels, and piping systems that handle harsh chemicals are all perfect uses for these forgings. Because of their resilience to saltwater corrosion, they are used in offshore components and seawater desalination systems in the maritime sector. Additionally, titanium Gr 11 is used in pollution control systems, aerospace parts, and power generation. Because of its mechanical strength and corrosion resistance, it is a material of choice for high-reliability applications in corrosive and harsh environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
