Based in Kolkata, India, Neil Metals is a top producer and supplier of high-performance titanium forgings intended for demanding and high-stress industrial uses. To meet the specific needs of the chemical, aerospace, medical, and marine industries, Neil Metals provides forged titanium components in a range of grades and sizes with an emphasis on quality, accuracy, and international compliance. The company uses cutting-edge forging technology and strong quality control systems to guarantee tight tolerances, excellent surface finishes, and mechanical integrity in every product. Neil Metals is dedicated to providing dependable titanium forgings with unparalleled strength, resistance to corrosion, and long-term durability.
Usually made in grades ranging from Grade 1 to Grade 5, titanium forgings have distinct compositions. While alloyed grades (such as Grade 5: Ti-6Al-4V) incorporate aluminium and vanadium for increased strength, pure titanium grades 1–4 contain more than 99% titanium. Grade 5 offers a tensile strength of approximately 950 MPa, yield strength of approximately 880 MPa, and elongation of approximately 10–14%. Titanium forgings are perfect for high-performance settings that demand both mechanical robustness and light weight because of their exceptional fatigue resistance, low density, and exceptional corrosion resistance.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
The durability of titanium forgings is ensured by factors such as alloy composition, proper heat treatment, precise forging processes, surface finishing, and resistance to corrosion, wear, and extreme temperatures in demanding environments.
The typical tensile strength of titanium forgings ranges from 900 to 1,200 MPa, depending on the alloy and heat treatment, offering excellent strength-to-weight ratio for various high-performance applications.
Closed-die forging in titanium production involves shaping the titanium metal between two pre-shaped dies under high pressure, ensuring precise dimensions, improved strength, and a refined grain structure for high-performance applications.
Because of their high strength-to-weight ratio and fatigue resistance, titanium forgings are widely used in aerospace applications, such as engine parts, landing gear, and structural frames. Because of their ability to withstand corrosion, they are used in seawater systems, ship shafts, and submarine hulls in the maritime sector. Because titanium is biocompatible, it can be used in medical applications such as dental fixtures, surgical instruments, and orthopaedic implants. Titanium forgings, which provide dependability in harsh conditions, are also essential in nuclear reactors, chemical processing, and automotive components. They are essential in safety-critical and precision-engineered applications due to their reliable performance under pressure.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
