A well-known producer and supplier of titanium bright bars, Neil Metals is based in Kolkata, India, and is renowned for its excellent mechanical performance, dimensional accuracy, and surface finish. These bars are appropriate for applications requiring strength, resistance to corrosion, and a polished appearance because they are made to the highest industry standards. Neil Metals provides titanium bright bars in a variety of grades and sizes to a broad range of industries, including the chemical, marine, medical, and aerospace sectors. The business guarantees consistent performance and dependability in every product it ships globally through stringent quality control and on-time delivery.
Commercially pure titanium (Grade 2) or titanium alloys such as Grade 5 (Ti-6Al-4V), which contain 6% aluminium and 4% vanadium, are commonly used to make titanium bright bars. They have outstanding corrosion resistance, low density (4.5 g/cm2), and high tensile strength (up to 950 MPa). The bars are perfect for high-performance applications because they have good fatigue strength, non-magnetic qualities, and biocompatibility. Their bright surface finish improves performance and appearance, especially in precision components where dimensional tolerance and visual quality are crucial.
Hardness, Brinell | 120 | 120 | annealed |
Hardness, Knoop | 132 | 132 | Estimated from Brinell. |
Hardness, Rockwell B | 70 | 70 | annealed |
Hardness, Vickers | 122 | 122 | Estimated from Brinell |
Tensile Strength, Ultimate | 240 MPa | 34800 psi | – |
Tensile Strength, Yield | 170 – 310 MPa | 24700 – 45000 psi | – |
Elongation at Break | 24 % | 24 % | – |
Reduction of Area | 35 % | 35 % | – |
Modulus of Elasticity | 105 GPa | 15200 ksi | In Tension |
Compressive Modulus | 110 GPa | 16000 ksi | – |
Poisson’s Ratio | 0.37 | 0.37 | – |
Charpy Impact | 310 J | 229 ft-lb | V-notch |
Shear Modulus | 45 GPa | 6530 ksi | – |
|
Physical Properties |
Metric |
English |
|
Density |
4.51 g/cc |
0.163 lb/in³ |
|
STANDARD |
WERKSTOFF NR. |
UNS |
|
Titanium |
3.7035 / 3.7165 / 3.7235 |
R50400 / R56400 / R52400 |
Titanium Bright Bars generally do not require corrosion protection coatings due to their natural resistance to corrosion. However, additional coatings may be used in highly aggressive environments for extra protection.
Titanium Round Bars offer exceptional strength-to-weight ratio, excellent corrosion resistance, and high durability, making them ideal for demanding applications in extreme environments.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@neilmetals.co.in
Because of their strength and light weight, titanium bright bars are frequently used in the aerospace industry to manufacture fasteners, structural elements, and aircraft components. Their biocompatibility makes them perfect for orthopaedic implants, dental tools, and surgical instruments in the medical field. They are used in the marine industry in fasteners exposed to seawater, pump components, and propeller shafts. Because of their resistance to corrosion, they are utilised in chemical processing in heat exchangers, reactor vessels, and fittings. These bars are also used in high-performance engineering applications where corrosion resistance, accuracy, and durability are crucial, as well as in defence equipment and automotive parts.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
