High-end Super Duplex Steel Bright Bars from Neil Metals, a well-known producer and supplier in Kolkata, India, are prized for their remarkable strength, finish, and corrosion resistance. Our bright bars are produced with precise dimensional accuracy and a superior surface finish through the use of sophisticated processes and rigorous quality checks. These bars are perfect for uses where performance and appearance are important considerations. Neil Metals provides a broad range of sizes and specifications to industries such as power generation, chemical processing, oil and gas, and marine. We are dedicated to providing dependable, high-performing materials along with prompt customer service and solutions.
The typical composition of Super Duplex Steel Bright Bars is 3–5% molybdenum, 6–8% nickel, 24–26% chromium, and trace amounts of manganese and nitrogen. A special combination of exceptional corrosion resistance and high strength is provided by this balanced dual-phase microstructure. These bars have yield strength above 550 MPa and tensile strength between 750 and 800 MPa. In environments with a lot of chloride, they are especially resistant to pitting, crevice corrosion, and stress corrosion cracking. The material retains good impact toughness, weldability, and fatigue resistance under demanding conditions, and the bright finish improves surface quality.
| Specifications | : | ASTM A276, ASME SA276 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | : | 6 mm to 120 mm. |
| Diameter | : | 6mm to 350mm Diameter |
| Thickness | : | 100 to 6000 mm Length |
| Tolerance | : | +/-0.2mm |
| Finish | : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | : | 1 to 6 Meters, Custom Cut Lengths |
| Form | : | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32750 | 0.030 max | 1.20 max | 0.80 max | 0.035 max | 0.020 max | 24.00 – 26.00 | 3.00 – 5.00 | 6.00 – 8.00 | 0.24 – 0.32 | 58.095 min |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32750/S32760 | 7.8 | 0.281 | 1350 | 2460 |
Super Duplex Steel Bright Bars are utilised in applications that demand exceptional corrosion resistance, superior finish, and exceptional mechanical strength. They are utilised in parts like pump shafts, fasteners, and valves in the oil and gas sector. They are essential to the maritime industry for shafting and saltwater-exposed structural components. Because of their robustness and ability to withstand extreme conditions, these bars are also perfect for power plants, desalination, chemical processing, and offshore platforms. They are appropriate for high-precision engineering, food processing equipment, and architectural applications needing both strength and aesthetic appeal because of their polished finish and exact tolerances.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Neil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kolkata, India
