For crucial industrial applications, Neil Metals, a reputable manufacturer and supplier in Kolkata, India, provides premium-grade stainless steel 904L square bars and rods. Our SS 904L products are renowned for their outstanding mechanical qualities, longevity, and resistance to corrosion. We provide square bars and rods that satisfy international standards for quality and performance, all while maintaining a dedication to precision engineering and client satisfaction. Our 904L square bars provide strength and dependability in demanding structural applications as well as harsh chemical environments. Neil Metals consistently produces high-quality exports to foreign markets and serves a broad spectrum of industries throughout India.
Non-stabilized austenitic stainless steel 904L has a low carbon content and a high alloy composition that includes 1–2% copper, 19–23% chromium, 23–28% nickel, and 4–5% molybdenum. Superior corrosion resistance is offered by this composition, particularly against acids like phosphoric and sulphuric. Even in challenging conditions, it provides good ductility, toughness, and tensile strength of 490–710 MPa. 904L functions well at both high and low temperatures and maintains its non-magnetic nature under all circumstances. In environments with a lot of chloride, it also resists stress corrosion, cracking, and pitting.
| Specifications | : | ASTM A276, ASME SA276 / ASTM A479 ASME SA479 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 904L Square Bars | : | Outside Diameter in the range of 4mm to 500mm |
| SS 904L Square Bars | : | 18mm ” 47mm (11/16″ to 1-3/4″) |
| Finish | : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | : | 1 to 6 Meters, Custom Cut Lengths |
| Form | : | Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu | |
| SS 904L | Min | – | – | – | – | – | 19 | 4 | 23 | 1 |
| Max | 0.02 | 2 | 1 | 0.045 | 0.035 | 23 | 5 | 28 | 2 |
| Grade | Tensile strength (MPa) | Yield Strength 0.2% Proof(MPa) | Elongation (% in 50mm) | Hardness – Brinell |
| 904L | 490 | 220 | 36 | 70-150 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | EN | EURONORM NAME |
| SS 904L | 1.4539 | N08904 | – | 904S13 | – | X1NiCrMoCuN25-20-5 |
| SQUARES | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
904L square bars and rods of stainless steel are frequently utilised in sectors where resistance to corrosion is essential. Acid production facilities, pulp and paper equipment, heat exchangers, marine components, and chemical and petrochemical processing are examples of common applications. They are perfect for use in storage tanks, piping systems, and pollution control equipment because of their resistance to strong acids, such as sulphuric acid. Because of their cleanliness and hygienic requirements, SS 904L square bars are also utilised in food processing and pharmaceutical equipment. They are appropriate for both structural and mechanical applications in demanding industrial settings due to their high strength, formability, and weldability.
Yes, we provide stainless steel 904L square bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@neilmetals.co.in
Stainless Steel 904L Square Rods are known for their exceptional corrosion resistance, high strength, and excellent weldability, making them ideal for harsh environments. They also exhibit good formability, durability, and resistance to pitting and crevice corrosion.
Yes, Stainless Steel 904L Square Bars can be recycled after use. Their high nickel and chromium content make them valuable for recycling, reducing waste and conserving resources.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
