Located in Kolkata, India, Neil Metals is a well-known manufacturer and supplier of premium stainless steel 904L round bars and rods that are renowned for their exceptional durability and resistance to corrosion. Neil Metals has years of experience producing stainless steel and produces goods that are designed to satisfy the exacting specifications of vital industries. Modern technology and strict quality control are used in the production of our SS 904L Round Bars and Rods to guarantee accuracy and dependability. These bars are dependable in industries like chemical processing, marine, oil and gas, and pharmaceuticals because they are perfect for corrosive and high-stress settings. Neil Metals guarantees client satisfaction and on-time delivery.
The low-carbon, high-alloy austenitic stainless steel 904L has 19–23% chromium, 23–28% nickel, 4-5 molybdenum, and 1-2 percent copper. Excellent resistance to strong reducing acids, particularly sulphuric acid, is provided by this composition. Its yield strength is about 220 MPa, its tensile strength is between 490 and 710 MPa, and its elongation is good at 35%. Even in extremely acidic and chloride-rich environments, the alloy retains its strength and resistance to corrosion. SS 904L is appropriate for extremely corrosive industrial applications due to its non-magnetic nature and remarkable weldability, which further improve its performance.
| Standards | ASTM / ASME |
| Designation | B 649, SB 649 |
| Grade | 904L Round Bars and Rods 904L Round Bars and Rods: ASTM B 649, ASME SB 649 |
EN/DIN | 1.4539 X1NiCrMoCu25-20-5 |
|---|---|
AFNOR | Z2CNDU25.20 |
UNS | N08904 |
AISI | 904L / F904L |
BS | 904S13 |
SS | 2562 |
OTHER | ASTM A182 ASTM A262 ASTM A479 ASTM B649 / ASME SB649 DIN 17440 EN10088-3 EN10272 NACE MR01-75 / ISO 15156 SEW 400-VdTÜV421 |
BRANDS | URANUS B6™ VLX904™ AL-904L™ CRONIFER 1925™ 2RK65™ |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
|---|---|---|---|---|---|---|---|---|---|
| SS 904L | 0.020 max | 2 max | 1 max | 0.040 max | 0.030 max | 19.0-23.0 | 4.0-5.0 max | 23.00 – 28.00 | 1.0-2.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35% |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
Cut to size on request (tolerance +2/-0 mm). Standard lengths of 904L Stainless Steel Bars 2000 mm up to 6000 mm available
5.0 | 45.0 |
6.0 | 50.0 |
7.0 | 55.0 |
8.0 | 60.0 |
9.0 | 65.0 |
10.0 | 70.0 |
12.0 | 75.0 |
16.0 | 80.0 |
20.0 | 90.0 |
25.0 | 100.0 |
30.0 | 130.0 |
35.0 | 160.0 |
40.0 | 904L.0 |
Because of their exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking, stainless steel 904L round bars and rods are frequently utilised in extremely corrosive and acidic environments. They are frequently found in pulp and paper industries, heat exchangers, marine and offshore structures, and chemical processing facilities. Additionally, the alloy finds application in gas scrubbing systems, oil refinery components, and pharmaceutical and food processing equipment. SS 904L is perfect for storage tanks, piping systems, and pressure vessels because of its strong resistance to sulphuric and phosphoric acids, which guarantees a long service life in demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
