Neil Metals, a renowned manufacturer and supplier of stainless steel 904L flat bars with headquarters in Kolkata, India, is renowned for providing industries all over the world with excellent corrosion-resistant solutions. These flat bars provide exceptional durability and performance in demanding environments because they are expertly crafted and strictly adhere to international standards. High-alloy, austenitic, low-carbon stainless steel 904L is perfect for demanding applications. Neil Metals is a reliable partner for customers in the chemical, pharmaceutical, marine, and processing industries because of its strong supply chain, emphasis on quality, and competitive pricing.
Stainless steel 904L flat bars have a maximum carbon content of 0.02% and are made up of 19–23% chromium, 23–28% nickel, 4–5% molybdenum, and 1-2 percent copper. Its resistance to corrosion is improved by this composition, particularly against reducing acids like sulphuric acid. Mechanically, 904L provides a minimum elongation of 35%, a yield strength of 220 MPa, and a tensile strength of 490–710 MPa. Even in challenging conditions, it maintains its high level of toughness and structural integrity. Because of its exceptional weldability and non-magnetic properties, it can be used for precision fabrication.
| Standard | ASTM B649, ASME SB649 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | Ni | Mo | Cr | Cu | C | Mn | Si | P | S |
| 904L | 23 – 28 | 4 – 5 | 19 – 23 | 1 – 2 | 0.02 max | 2.0 max | 1.0 max | 0.045 max | 0.035 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.05 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | AFNOR | JIS | BS | KS | EN |
| 904L | 1.4539 | N08904 | Z2NCUD31-20AZ | SUS 890L | 904S13 | STS 317J5L | X1NiCrMoCu25-20-5 |
Because of their exceptional resistance to corrosion from strong acids and chloride stress, stainless steel 904L flat bars are used extensively in chemical processing, pharmaceutical equipment, marine structures, and pollution control systems. They are perfect for parts of oil refineries, heat exchangers, condenser tubes, and evaporators. They are appropriate for use in the textile, pulp and paper, and food processing industries due to their non-reactive surface and exceptional durability. Furthermore, 904L flat bars are used in seawater handling systems, desalination facilities, and architectural structures where resistance to pitting and crevice corrosion is essential.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
