To satisfy the needs of diverse industrial sectors, Neil Metals, a well-known manufacturer and supplier in Kolkata, India, provides premium-quality stainless steel 431 flat bars. Neil Metals is well-known for producing high-performance, long-lasting stainless steel products, and they make sure that every 431 Flat Bar is produced with strict quality controls and cutting-edge methods. Our 431 Flat Bars are well-known for their exceptional mechanical strength, resistance to corrosion, and ease of machining, making them perfect for applications that demand both precision and toughness. Neil Metals is dedicated to offering consumers in India and abroad dependable stainless steel solutions.
About 15–17% chromium, 1.25–2.50% nickel, and 0.12–0.20% carbon make up the martensitic stainless steel alloy known as Stainless Steel 431, which also contains trace amounts of silicon and manganese. It provides good hardness, moderate corrosion resistance, and high tensile strength (up to 850 MPa). 431 has outstanding toughness and fatigue resistance following the right heat treatment. Compared to other martensitic grades, it is more machinable, which makes it appropriate for precision parts. It is a versatile material for demanding engineering applications because of its balance of corrosion resistance and mechanical strength.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| ement | C | Cr | Mn | Ni | P | S | Si |
| SS 431 | 0.20 | 17.00-15.00 | 1.00 | 2.50-1.25 | 0.040- | 0.030 | 1.00 |
| Element | Density | Electrical Resistivity | Modulus of Elasticity |
| SS 431 | 0.2800 lb/inch³ | 70° Ohms (circ mil./ft.) | 29.0 X 10^3 |
| Flat Bar | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.49 | 1.60 |
| 18 | 0.62 | 2.02 |
| 20 | 0.76 | 2.49 |
| 22 | 0.92 | 3.02 |
| 25 | 1.19 | 3.90 |
| 28 | 1.49 | 4.89 |
| 28 | 1.49 | 4.89 |
| 30 | 1.71 | 5.61 |
| 32 | 1.95 | 6.38 |
| 36 | 2.46 | 8.08 |
| 38 | 2.74 | 9.00 |
| 40 | 3.04 | 9.97 |
| 45 | 3.85 | 12.62 |
| 50 | 4.75 | 12.62 |
| 56 | 8.96 | 19.55 |
| 60 | 6.84 | 22.44 |
| 65 | 8.03 | 26.34 |
| 70 | 9.31 | 30.54 |
| 75 | 10.69 | 35.06 |
| 80 | 12.16 | 39.89 |
| 90 | 15.39 | 50.49 |
| 100 | 19 | 62.34 |
Numerous applications call for stainless steel 431 flat bars’ exceptional machinability, high strength, and resistance to corrosion. Oil and gas, automotive, marine, and aerospace are examples of common industries. For the production of shafts, bolts, fasteners, pump parts, and valves subjected to mildly corrosive conditions, these flat bars are perfect. They are also utilised in chemical processing equipment, turbine blades, and aircraft parts because of their tensile strength and hardness. 431 Flat Bars are a popular option for load-bearing and structural elements in both residential and commercial applications due to their adaptability and ability to withstand mechanical stress.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
