Based in Kolkata, India, Neil Metals is a reputable producer and supplier of 420 square bars and rods of stainless steel, providing high-quality goods to a variety of industries. Neil Metals offers SS 420 square bars and rods, which are renowned for their high hardness, wear resistance, and durability. They are also known for their precision machining and adherence to international quality standards. To satisfy a range of engineering and industrial needs, these products come in a variety of sizes and finishes. Neil Metals is a popular option in both domestic and foreign markets thanks to its dedication to reliable quality, affordable prices, and prompt delivery.
With a typical composition of 12–14% chromium and up to 0.15% carbon, stainless steel 420 is a martensitic stainless steel that can be heat-treated for greater hardness. It has a high tensile strength (roughly 700–950 MPa) and yield strength of about 345 MPa, and it exhibits good corrosion resistance in mild environments. It has moderate ductility and excellent hardness when hardened (up to 50 HRC). When hardened, SS 420 exhibits fair machining characteristics and is magnetic both in its annealed and hardened states.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 420 | 0.15 | 14.0 | 1.00 | – | 0.04 | 0.03 | 1.00 |
| Element | Tensile Strength | Yield Strength | Elongation | Hardness |
| SS 420 | 95,000 | 50,000 | 25 | 175 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 420 | 1.4021 | S42000 | SUS 420 J1 | 420S29 | – | – | FeMi35Cr20Cu4Mo2 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Because of its exceptional hardness and polishability, stainless steel 420 square bars and rods are frequently used in the cutlery industry to make knife blades, surgical tools, and scissors. They are also used for shafts, gears, and valve parts in the automotive industry. SS 420 is perfect for moulds, dies, and bearing assemblies in the engineering and tooling sectors. It is appropriate for pump shafts, fasteners, and springs due to its high wear tolerance and resistance to corrosion. Applications needing strength, edge retention, and abrasion resistance in dry and mildly corrosive environments favour this alloy.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
