One of the top producers and suppliers of stainless steel hexagon bars in Kolkata, India, is Neil Metals, a reputable brand in the stainless steel sector. Offering a large selection of stainless steel hexagonal bars in different grades and sizes to satisfy the varied needs of industries nationwide, we are dedicated to quality and accuracy. Our hex bars are produced using high-quality raw materials and cutting-edge production techniques, and they are well-known for their exceptional strength, durability, and resistance to corrosion. We provide dependable and prompt supply to support your engineering and fabrication projects in a variety of industries, including construction, petrochemicals, automotive, and more.
Depending on the grade (e.g., 304, 316, 321), stainless steel hex bars may contain additional molybdenum, manganese, and carbon in addition to the usual 16–20% chromium and 8–14% nickel. These bars have good elongation and hardness, a yield strength of about 250 MPa, and an exceptional tensile strength of up to 700 MPa. The austenitic structure improves ductility and resistance to corrosion. Hex bars are perfect for applications where chemical resistance and structural integrity are crucial, particularly in harsh environments, because they are simple to machine and fabricate while still having a high mechanical strength.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 410 | 0.15 | 11.5-13.5 | 1.00 | 0.75 | 0.040 | 0.030 | 1.00 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Applications requiring exceptional corrosion resistance, high strength, and dimensional accuracy frequently use stainless steel hex bars. They are perfect for heavy machinery parts, fasteners, shafts, valve parts, marine fittings, and structural supports. In tool and mechanical assembly applications, their hexagonal shape offers exceptional torque and grip. Hex bars are widely used for both practical and decorative reasons in a variety of industries, including construction, power generation, food processing, oil and gas, chemical processing, and the automobile industry. They can be used in high-temperature, outdoor, and indoor settings due to their resilience to oxidation and pitting.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
