Neil Metals is a reputed and well-established Stainless Steel 316Ti Forgings manufacturer and supplier in Kolkata, India. With its commitment to quality, strength, and customer satisfaction, Neil Metals caters to various industries such as petrochemical, marine, energy, and infrastructure. With state–of-the-art manufacturing technology and expert craftsmanship, the company produces forgings that strictly adhere to national and international standards. Renowned for punctual delivery and tailor-made solutions, Neil Metals is an ideal partner for customers looking for corrosion-resistant, high-temperature stainless steel forgings specifically designed to match challenging operating conditions and targeted industrial uses.
Stainless Steel 316Ti Forgings are produced from a titanium-stabilized austenitic stainless steel alloy that offers high resistance to intergranular corrosion. The standard chemical composition contains 16–18% Chromium, 10–14% Nickel, 2–3% Molybdenum, and a minimum amount of Titanium to stabilize the material. Other constituents are Carbon, Manganese, Silicon, and Phosphorus in limited proportions. The material provides a tensile strength around 515 MPa, a yield strength of 205 MPa, and 40% elongation, suitable for use where high strength and thermal resistance are needed in corrosive conditions.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316Ti | 0.08 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Yes, Stainless Steel 316Ti can be forged into custom shapes. Its excellent formability and resistance to corrosion make it suitable for creating complex designs required in various industries.
Yes, Stainless Steel 316Ti forgings are ideal for structural applications. Their excellent corrosion resistance, high strength, and ability to withstand extreme environments make them suitable for marine, chemical, and architectural structures.
Yes, Stainless Steel 316Ti forgings are ideal for structural applications. Their excellent corrosion resistance, high strength, and ability to withstand extreme environments make them suitable for marine, chemical, and architectural structures.
Stainless Steel 316Ti Forgings find extensive application in industries requiring high performance under corrosive and high-temperature conditions. The uses are pressure vessels, heat exchangers, marine fittings, exhausts, flanges, and valves. Because of their chloride resistance and acid-proofing, they are particularly useful in chemical processing, desalination plants, offshore oil rigs, and drug manufacturing. Their titanium content avoids sensitization upon welding and prolonged heating, making them long-lasting and structurally sound. These forgings are specifically suited for application under aggressive conditions where corrosion resistance and mechanical stress are paramount to the success of operations.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
