Based in Kolkata, India, Neil Metals is a reputable producer and supplier of premium 316L Hex Bars and Rods made of stainless steel. These bars are perfect for crucial industrial applications because of their remarkable resistance to corrosion, especially in acidic and chloride environments. Our 316L hex bars and rods are expertly crafted to meet international standards and provide exceptional strength, formability, and weldability. To satisfy a variety of industry demands, we offer a large selection of sizes and personalised finishes. Neil Metals serves customers in India and international markets with a dedication to quality, prompt delivery, and customer satisfaction.
Chromium (16–18%), nickel (10–14%), molybdenum (2–3%), and very little carbon (maximum 0.03%) are all present in stainless steel 316L Hex Bars/Rods. By reducing carbide precipitation, the low carbon improves corrosion resistance while welding. Even at cryogenic temperatures, this austenitic stainless steel shows outstanding toughness, yield strength (~170–220 MPa), and high tensile strength (about 485–585 MPa). Better mechanical engagement and grip are offered by the hexagonal shape. In addition to having outstanding formability and being non-magnetic when annealed, 316L is appropriate for demanding applications requiring strength, corrosion resistance, and ease of fabrication.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316l | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 3.00 max | 0.10 max |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316l | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 3.00 max | 0.10 max |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Industries that require high corrosion resistance and low carbon content frequently use stainless steel 316L hex bars and rods. Because of their resistance to acids and chlorides, they are perfect for use in chemical processing, pharmaceutical equipment, and marine applications. They can be used to produce precision parts like bolts, nuts, and fasteners because of their hex shape. 316L is prized for its hygienic qualities in the food and beverage sector. It is also utilised in the paper and pulp industries, heat exchangers, medical devices, and architectural structures. It is an excellent option for structural and engineering applications due to its durability and weldability.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
