Stainless Steel 316 Hex Bars and Rods of superior quality are available from Neil Metals, a well-known manufacturer and supplier with headquarters in Kolkata, India, for a variety of industrial uses. Our 316 hex bars and rods are made with premium raw materials and precision technology, and they are well-known for their exceptional strength, formability, and resistance to corrosion. These goods are perfect for the food processing, chemical, pharmaceutical, and marine industries and satisfy international standards. Neil Metals guarantees that every product offers unparalleled dependability, durability, and performance and comes in a range of sizes and finishes. We are a preferred supplier in India and international markets because of our dedication to quality and prompt delivery.
Chromium (16–18%), nickel (10–14%), and molybdenum (2–3%) are commonly found in stainless steel 316 Hex Bars/Rods, with a low carbon content to improve corrosion resistance. In chloride environments, this austenitic stainless steel offers exceptional resistance to pitting and crevice corrosion. Mechanical characteristics include a yield strength of about 205 MPa and a tensile strength of roughly 515–585 MPa. Even at cryogenic temperatures, it provides exceptional toughness and retains good ductility and weldability. Applications needing strength, accuracy, and resistance to corrosion can benefit from the hexagonal shape’s improved torque transmission and grip.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316 | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 0.03 max | 0.75 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | – | – | 515 Min | 205 Min | 40% Min |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Hex bars and rods made of stainless steel 316 are frequently used in settings that demand a high level of strength and corrosion resistance. Because of their superior resistance to saltwater, they are utilised in the marine industry for boat fittings, shafts, and fasteners. They are used in reactor vessels, valves, and pipelines in the chemical processing and pharmaceutical industries. They are appropriate for food and beverage equipment because of their hygienic qualities. When producing fasteners, nuts, and bolts—where torque control is crucial—the hex shape is especially advantageous. Furthermore, 316 hex bars and rods are utilised in architectural and structural applications, providing strength and beauty in demanding settings.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
