These Stainless Steel 316 Flat Bars are made up of 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, along with low carbon content and trace elements like manganese, phosphorus, sulfur, and silicon. The inclusion of molybdenum greatly boosts corrosion resistance, especially against chlorides and industrial solvents. SS 316 boasts a tensile strength of around 515 MPa and a yield strength of about 205 MPa. It retains excellent strength and toughness across a wide temperature range and offers good welding and forming characteristics, making it a versatile choice in the world of austenitic stainless steel.
Standard : ASTM A276, ASME SA276
Dimensions : EN, DIN, JIS, ASTM, BS, ASME, AISI, ASTM, ASME
Flat Bar Size : 2mm ~ 100mm
Thickness : 1/8″ – 3″
Width : 3/8” – 8”
finish : Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black
| Element | SS 316 |
| C | 0.08 max |
| Mn | 2.0 max |
| Si | 1.0 max |
| P | 0.045 max |
| S | 0.030 max |
| Cr | 16 – 18 |
| Ni | 11 – 14 |
| Mo | 2 – 3 |
| Fe | 67.845 min |
| Element | SS 316 |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17-11-02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
Stainless Steel 316 flat bars and rods are widely used in marine environments, chemical processing, food processing, medical equipment, and construction projects due to their excellent corrosion resistance.
Neil Metals is a leading manufacturer and supplier of premium-quality Stainless Steel 316 Flat Bar and Rods, catering to industrial, commercial, and personal needs across the India and worldwide.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@neilmetals.co.in
You’ll find Stainless Steel 316 Flat Bars in a wide array of applications that demand high corrosion resistance and strength. They’re commonly used in marine structures, bridges, food processing equipment, chemical storage tanks, pharmaceutical machinery, and architectural components. Additionally, they play a crucial role in the fabrication of frames, supports, brackets, and base plates for construction and industrial projects. SS 316 flat bars are particularly popular in coastal and saltwater environments due to their outstanding resistance to pitting and crevice corrosion. Their durability, ease of shaping, and low-maintenance nature make them perfect for both structural and aesthetic uses.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Neil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kolkata, India
