Neil Metals, based in Kolkata, India, is a well-respected manufacturer and supplier of top-notch Stainless Steel 304 Forgings. Renowned for their outstanding corrosion resistance, strength, and versatility, SS 304 forgings find their way into various industries, including food processing, pharmaceuticals, petrochemicals, and construction. At Neil Metals, we craft 304 stainless steel forgings using premium raw materials and cutting-edge forging technology, ensuring exceptional dimensional accuracy and mechanical performance. With a strong focus on quality, compliance, and customer satisfaction, we deliver customized forging solutions that meet international standards, perfect for demanding structural and industrial applications.
Stainless Steel 304 Forgings are primarily made up of chromium (18–20%) and nickel (8–11%), along with trace amounts of manganese, silicon, and carbon. This unique blend guarantees excellent corrosion resistance, particularly in oxidizing environments. SS 304 forgings boast a tensile strength of around 515 MPa, a yield strength of 205 MPa, and an elongation of 40%. The Brinell hardness is approximately 201 HB. This alloy maintains impressive toughness and formability across a broad temperature range, offering great weldability and machinability, making it ideal for structural, mechanical, and pressure-bearing applications in various industries.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 304L | 1.4306 / 1.4307 | S30403 | SUS 304L | 3304S11 | 03Х18Н11 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 |
Stainless Steel 304 Forgings are widely utilized across many sectors due to their remarkable corrosion resistance, strength, and versatility. You’ll often find them in valves, flanges, fittings, shafts, pump components, and structural supports. In the food and beverage industry, 304 is perfect for sanitary equipment because of its non-reactive and easy-to-clean nature. It’s also employed in chemical processing equipment, architectural structures, marine hardware, and pharmaceutical machinery. SS 304 forgings consistently perform well in mildly corrosive environments, making them a reliable choice for many applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Neil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kolkata, India
