Neil Metals, based in Kolkata, India, is a well-known manufacturer and supplier of top-quality Stainless Steel 304H Bars and Rods, providing dependable solutions for high-temperature and pressure applications. Crafted for exceptional strength and resistance to corrosion, SS 304H is the high-carbon version of 304 stainless steel, making it perfect for structural components that face elevated temperatures. Our 304H bars and rods are produced with precision, using high-grade raw materials and cutting-edge processes. With a strong focus on quality, customization, and timely delivery, Neil Metals caters to a diverse range of industries, including oil & gas, power generation, chemical, and petrochemical sectors.
Stainless Steel 304H Bars and Rods mainly consist of chromium (18–20%) and nickel (8–11%), with a higher carbon content (0.04–0.10%) compared to standard 304. This increased carbon enhances strength and creep resistance at high temperatures. Typical mechanical properties include a tensile strength of about 585 MPa, yield strength of 240 MPa, and an elongation of 40%. The Brinell hardness is roughly 217 HB. This alloy provides good oxidation resistance up to 870°C and maintains excellent structural integrity under heat, making it suitable for pressure vessels, heat exchangers, and high-temperature industrial systems.
| Grade | Stainless Steel 304H (UNS S30409) |
|---|---|
| Specification | ASTM A276, ASTM A479 |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Hollow Bar | 32 OD x 16 ID to 250 OD x 200 ID |
| Square bar size | 4 to 100mm |
| Section | 3.0 to 12.0mm thickness |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Billet Size | 1/2″ to 495mm Diameter |
| Channel Bar | 80 x 40 to 150 x 75 mm section; 5 to 6 mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Angle bar size | 3*20*2~12*100*100 mm |
| Form | Rings, Profiles, Hollow, Flat Bar, Square, Round, Rectangle, Triangle, Rod, Half Round Bar, T-Bar, Hex (A/F), Precision Ground Bar, Channel Bar, Blocks, Round Rod, Threaded, Billet, Ingot, I/H Bar, Forging etc. |
| Technique | Cold Drawn, Rod, Hot Rolled, Cold Rolled, Forged Round Bar |
| Condition | annealed, Hardened & tempered |
| Surface | Cold Drawn, Polished, Bright, Hot Rolled Pickled, Sand Blasting Finished,Hairline |
| Element | SS 304H |
| C | 0.10 max |
| Ni | 8.0 – 10.5 |
| P | 0.045 max. |
| Mn | 2.00 max |
| Si | 0.75 max |
| S | 0.03 max. |
| Cr | 18.0 – 20.0 |
| Element | SS 304H |
| Melting Point | 1400 ℃ |
| Density | 8 |
| Hardness (Brinell) | 201 |
| Yield Strength (0.2%Offset) | 205 |
| Tensile Strength | 515 |
| Elongation | 40 |
|
Type |
SIZES (Inches) |
ISO Tolerance |
SIZES (mm) |
|---|---|---|---|
|
Peeled and Polished |
1.50″ to 6.00″ |
h11-DIN 1013 |
40.00 to 150.00 |
|
Cold Drawn and Ground |
5/6″ to 2.50″ |
h9-h8-h11-h10 |
10.00 to 75.00 |
|
Cold Drawn and Polish |
1/8″ to 3.00″ |
h9-h8-h11-h10 |
3.00 to 75.00 |
|
Peeled and Ground |
3/4″ to 2.00″ |
h10-h9-h11 |
20.00 to 50.00 |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 304H | S30409 | 1.4301 |
Stainless Steel 304H Bars and Rods find extensive use in high-temperature and high-pressure settings, especially in the chemical, petrochemical, oil & gas, and power generation sectors. They are perfect for boilers, heat exchangers, pressure vessels, superheaters, and piping systems where strength at elevated temperatures is crucial. The higher carbon content offers improved creep resistance, making 304H ideal for applications that involve continuous exposure to temperatures above 500°C. Additionally, it boasts good weldability and corrosion resistance in oxidizing environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
