Kolkata, India-based Neil Metals is a well-established producer and provider of **Stainless Steel 304 Forgings**, offering high-precision, hot-worked parts that comply with international standards like ASTM A182 and EN 10204. Employing controlled forging in the range of 927–1260 °C, their technique improves grain structure for increased strength, durability, and resistance to corrosion. Supplying industries such as chemical, food processing, petrochemical, power generation, and marine, Neil Metals integrates strict quality control, competitive pricing, and reliable delivery to guarantee high-performance forged components for severe applications.
**304 Stainless Steel Forgings** are made up of 18–20% chromium, 8–10.5% nickel, with 0.08% carbon as the maximum, and add manganese, silicon, phosphorus, and sulfur according to ASTM/EN standards ([steelpipesfactory.com][1]). Mechanically, they provide a tensile strength of at least 515 MPa, yield strength of about 205 MPa, and elongation of 35–40% ([steelpipesfactory.com][1]). Forging provides better grain flow, which increases impact toughness and resistance to fatigue, while maintaining superior corrosion properties and the ability for intermittent service up to \\~925 °C.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 | – |
| (UNS) | Tensile Strength (MPa) ≥ | Yield Strength ≥ (MPa) at 0.2% Offset | Elongation in 50 mm (%, ≥) | Reduction of Area, %, ≥ | Brinell Hardness (HBW) ≤ | Rockwell Hardness (HRBW) ≤ | Product | Condition |
| 304 (UNS S30400) | 515 | 205 | 40 | – | 201 | 92 | Plate, Sheet, and Strip | – |
| 515 | 205 | 40 | 50 | – | – | Bars and Shapes | Hot finished | |
| 620 | 310 | 30 | 40 | – | – | Cold finished, Dia ≤ 12.7mm | ||
| 515 | 205 | 30 | 40 | – | – | Cold finished, Dia. > 12.7mm |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 304 | 1.4301 | S30400 | SUS 304 | 304S31 | 08Х18Н10 | Z7CN18‐09 | X5CrNi18-10 |
304 Stainless Steel Forgings have extensive applications in **valve bodies, pump casings, heat exchanger parts, and shafts**, enjoying the advantages of high strength, corrosion resistance, and accurate shape ([walkson.com][2]). In **chemical, petrochemical, pharmaceutical, and food processing industries**, they provide hygienic operation and acid, alkali, and cleaning chemical resistance. In addition, they are used in **power generation, marine, and offshore applications**—including boiler components, marine bolts, and structural elements—where performance in corrosive, wet, or salty conditions is vital .
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
