Neil Metals is a prominent manufacturer and supplier of Stainless Steel 304 Rods and Bars, with its head office at Kolkata, India. It is renowned for its dedication to quality, accuracy, and dependability and offers its products to a diverse range of industries such as construction, auto, food processing, and chemical equipment manufacturing. Using state-of-the-art manufacturing units and a pool of expert professionals, the organization supplies stainless steel bars and rods both as per Indian standards as well as global requirements. Neil Metals is known for offering corrosion-free, long-lasting, and price-effective stainless steel solutions that are customized according to the precise needs of clients from different industries.
Neil Metals’ Stainless Steel 304 Bars and Rods are produced using an austenitic stainless steel alloy with about 18% Chromium and 8% Nickel. This alloy provides good corrosion resistance, satisfactory forming and welding properties, and superior strength. Other components are Manganese, Silicon, and a low amount of Carbon content (up to 0.08%). The material generally has a tensile strength of 515–750 MPa, a yield strength of 205 MPa, and elongation of approximately 40%. SS 304 retains its mechanical strength over a broad range of temperatures and can be used under both cryogenic and high-temperature conditions without loss of performance or strength.
| Specification | ASTM A479/ SA479 ASTM A276/ ASME SA276 |
|---|---|
| Grade | Stainless Steel 304 (UNS S30400) |
| Hex Bar size | 18 to 57mm (11/16″ – 2-3/4″) |
| Round bar size | OD 4mm to 500mm |
| Square bar size | 18mm to 47mm (11/16″- 1-3/4″) |
| Billet Size | 1/2″- 495mm Dia. |
| Rectangles Size | 33 x 30mm – 295 x 1066mm |
| Bright Bar | OD 4mm to 100mm |
| Tolerance | K12 H12, K10, H9, H11, H8, H13K9, H10, K11, or as per need |
| Flat bar size | 1/2” to 10” in thickness of 2 to 150mm |
| Angle bar size | 3*20*20~12*100*100 |
| Finish | centreless ground, Cold (bright) drawn, hot rolled, peeled, smooth turned, hot rolled annealed, slit rolled edge, Bright, Rough Turned, Grinding, Polish & Black |
| Form | Flat Bar, Hollow, Round, Square, Triangle, Rectangle, Half Round Bar, Rod, T-Bar, Precision Ground Bar, Hex (A/F), Blocks, Channel Bar, Threaded, Round Rod, Billet, Profiles, I/H Bar, Ingot, Rings, Forging etc. |
| Technique | 440C Stainless Steel Hot Rolled, Cold Drawn, Rod, Forged Round Bar, Cold Rolled |
| Condition | annealed, Hardened & tempered |
| Section | 3.0 -12.0 mm thickness, 80 x 40 to 150 x 75mm section |
| Channel Bar | 5.0 – 6.0mm thickness |
| Surface | Bright, Cold Drawn, Hot Rolled Pickled, Sand Blasting Finished, Polished, Hairline |
| Hollow Bar | 32mm OD x 16mm ID – 250mm OD x 200mm ID |
| Grade | Mn | C | Si | S | P | Cr | Ni | Mo | N |
| SS 304 | 2 maximum | 0.08 maximum | 0.75 maximum | 0.030 maximum | 0.040 maximum | 18 – 20 | 8 – 11 | – | – |
| Density | Elongation | Tensile Strength | Melting Point | (0.2%Offset) Yield Strength |
| 8.0 g/cm3 | 35 % | MPa – 515 , Psi – 75000 | 1400 °C (2550 °F) | MPa – 205, Psi – 30000 |
|
Type |
SIZES (Inches) |
ISO Tolerance |
SIZES (mm) |
|---|---|---|---|
|
Peeled and Polished |
1.50″ to 6.00″ |
h11-DIN 1013 |
40.00 to 150.00 |
|
Cold Drawn and Ground |
5/6″ to 2.50″ |
h9-h8-h11-h10 |
10.00 to 75.00 |
|
Cold Drawn and Polish |
1/8″ to 3.00″ |
h9-h8-h11-h10 |
3.00 to 75.00 |
|
Peeled and Ground |
3/4″ to 2.00″ |
h10-h9-h11 |
20.00 to 50.00 |
|
STANDARD |
UNS |
WERKSTOFF NR. |
BS |
JIS |
AFNOR |
GOST |
EN |
|
SS 304 |
S30400 |
1.4301 |
304S31 |
SUS 304 |
Z7CN18‐09 |
08Х18Н10 |
X5CrNi18-10 |
Stainless Steel 304 Bars and Rods offer excellent corrosion resistance, high tensile strength, and good machinability. They are also highly resistant to oxidation and can withstand various industrial and environmental conditions, making them suitable for a wide range of applications.
Stainless Steel 304 Bars and Rods are widely used in industries such as food processing, automotive, chemical, pharmaceutical, and construction. They are used for manufacturing parts like shafts, fasteners, pipes, and structural components due to their durability and corrosion resistance.
Yes, Stainless Steel 304 Bars and Rods perform well in high-temperature environments, with the ability to withstand temperatures up to 870°C (1600°F) in intermittent service. This makes them suitable for applications in heat exchangers, ovens, and other high-heat environments.
304 Stainless Steel Bars and Rods find extensive application due to their superior resistance to corrosion, formability, and versatility. They are extensively used in applications like architectural buildings, food processing machinery, kitchen appliances, car trim, chemical containers, and piping systems. SS 304 is particularly appropriate for application in environments under exposure to moisture, mild acids, and other corrosive substances. Its cleanliness and ease of maintenance are also reasons why it is used extensively in the dairy and pharmaceutical industry. Such bars and rods are well suited for fabrication, machining, and welding operations in various commercial and industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
