Neil Metals, a well-established Kolkata-based manufacturer and supplier, specializes in offering top-quality Stainless Steel 303 Hex Bars and Rods renowned for their superior machinability and corrosion resistance. Precise and reliable, Neil Metals supplies 303 stainless steel items that conform to international standards and find applications in the automotive, manufacturing, and engineering industries. Their 303 hex bars and rods are engineered to provide easy machining without compromising on durability, making them perfect for the manufacture of intricate, precision parts. With a focus on quality and delivery, Neil Metals is a sought-after supplier for stainless steel solutions both within and outside India.
Stainless Steel 303 Hex Bars and Rods are an austenitic stainless steel alloy containing around 17–19% chromium, 8–10% nickel, and sulfur and phosphorus as additions to improve machinability. The carbon percentage is around 0.15%, offering good strength with a tensile strength of about 620 MPa and a yield strength of 310 MPa. These bars have good corrosion resistance in moderately corrosive conditions but are weaker than 304 owing to sulfur present in them. Hexagonal structure provides better grip and machining effectiveness for the production of precision components.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| Stainless Steel 303 | 0.15 max | 2 max | 1 max | 0.20 max | 0.15 min | 17.0-19.0 | – | 8 – 10 |
| Element | Tensile Strength | Yield Strength | Elongation | Reduction in Area | Hardness |
| SS 303 | Psi – 85,000 | Psi – 45,000 | 50% | 55% | Rb 180 |
| Element | Density, lb/in3 | Modulus of Elasticity, psi | Linear Expansion, 68-212°F, /°F | Thermal Conductivity, Btu/ft hr°F | Heat Capacity, Btu/lb°F | Electrical Resistivity, Ω-inch |
| SS 303 | 0.285 | 29 x 106 | 9.4 x 10-6 | 8.7 | 0.12 | 27.6 x 10-6 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 303 Hex Bars and Rods find extensive applications in applications needing high machinability with acceptable corrosion resistance. Applications include the production of gears, shafts, bolts, screws, and other precision parts in which ease of manufacture is paramount. They are suitable for motor vehicle components, machinery parts, and instrumentation fittings. 303 hex bars are less applicable to highly corrosive environments but are suitable in applications with moderate chemical exposure, lubrication, and atmospheric conditions. Their hexagonal design facilitates safe handling and close machining in automated manufacturing environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
