Neil Metals, based in Kolkata, India, has earned a solid reputation as a reliable manufacturer and supplier of Stainless Steel 17-4PH Forgings. These components are designed to be high-strength and corrosion-resistant, making them perfect for tough industrial applications. With their impressive mechanical properties and ability to harden through a single heat treatment, these forgings find their way into various sectors, including aerospace, marine, and chemical processing. Neil Metals offers 17-4PH forgings in a variety of shapes and sizes—think shafts, rings, discs, and even custom parts—while ensuring they meet international standards. Their commitment to precision, durability, and timely delivery means they consistently provide dependable forging solutions to both local and global clients.
When it comes to composition, Stainless Steel 17-4PH Forgings contain about 17% chromium and 4% nickel, along with copper and niobium (or columbium) for precipitation hardening. This alloy boasts remarkable mechanical strength, achieving tensile strength up to 1100 MPa and yield strength around 1000 MPa after heat treatment. It strikes a balance between high hardness, moderate corrosion resistance, and good toughness, even in tough environments. Plus, the material is magnetic and retains solid mechanical properties in both its base and hardened states.
Specifications ASTM B564 / ASME SB564 AMS 5644
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | C | Ni | Si | S | Mn | P | Cr | Cu | |
| SS 17-4 PH | min. | – | 3.0 | – | – | – | – | 15.00 | 3.0 |
| max. | 0.07 | 5.0 | 1.00 | 0.03 | 1.0 | 0.04 | 17.5 | 5.0 | |
| Grade | Tensile Strength (ksi) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (ksi) min | Hardness |
| 17-4 PH | 135 | 16 | 105 | 277 |
| STANDARD | UNS | WERKSTOFF NR. |
| 17-4 PH | S17400 | 1.4542 |
The ideal temperature range for forging Stainless Steel 17-4PH is 1850°F to 2050°F (1010°C to 1120°C). Post-forging, annealing or solution treating is necessary to achieve optimal properties.
Yes, Stainless Steel 17-4PH forgings can be forged into custom shapes. This alloy offers excellent strength, corrosion resistance, and machinability, making it suitable for precision custom forging applications.
The forging process for Stainless Steel 17-4PH typically takes several hours, including heating, shaping, and cooling. The exact duration depends on part size, complexity, and specific forging techniques used.
These Stainless Steel 17-4PH Forgings are widely utilized in the aerospace industry for structural parts, fasteners, and landing gear components. They also play a crucial role in the oil and gas sector, where they are used for valve bodies, pump shafts, and downhole tools. In the marine industry, you’ll find them in high-strength, corrosion-resistant hardware and drive components. Additionally, these forgings are perfect for chemical plants, paper mills, and food processing equipment, where strength and cleanliness are paramount. The unique combination of strength, corrosion resistance, and ease of fabrication makes 17-4PH forgings a top choice for precision-engineered, high-performance applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
