Neil Metals, a trusted manufacturer and supplier located in Kolkata, India, specializes in high-quality Nickel Alloy 201 Forgings designed for critical industrial applications that demand outstanding corrosion resistance and thermal stability. With a strong focus on precision and quality, Neil Metals crafts forgings that adhere to international standards and are customized to meet client needs. Nickel Alloy 201 is a low-carbon variant of Nickel 200, making it perfect for situations involving high temperatures and reducing environments. With a wealth of technical expertise and efficient delivery, Neil Metals provides Nickel 201 forgings to industries throughout India and beyond, ensuring top-notch performance, reliability, and durability.
Nickel Alloy 201 is a commercially pure wrought nickel, boasting a composition of Nickel (≥99.6%) and a very low Carbon content (≤0.02%), which significantly enhances its resistance to graphitization at elevated temperatures. It showcases impressive mechanical properties, including a tensile strength of about 400–450 MPa and remarkable ductility. This alloy excels in both acidic and alkaline settings, maintaining its strength and corrosion resistance even at temperatures reaching 600°C. Additionally, Nickel 201 offers excellent thermal and electrical conductivity, along with low magnetic permeability.
| Specifications | ASTM B564, ASME SB564 |
|---|---|
| Standard | BS 3072, BS 3073, BS 3074, BS 3075, BS 3076, NA11 DIN 17740, 17750, 17751, 17752, 17753, 17754, DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
Yes, Nickel Alloy 201 can be forged into custom shapes. Its excellent ductility and malleability make it ideal for creating tailored components to meet specific design and application requirements.
Post-forging operations for Nickel Alloy 201 typically include heat treatment to enhance mechanical properties, machining for precision shaping, and surface finishing to ensure corrosion resistance and optimal performance.
To determine if Nickel Alloy 201 forgings meet your needs, evaluate their chemical composition, mechanical properties, and corrosion resistance against your application requirements. Consulting with experts or suppliers can ensure the material's suitability.
Nickel Alloy 201 Forgings find extensive use in the chemical processing, electronics, aerospace, and marine sectors. They are particularly well-suited for applications involving caustic alkalis, food processing, synthetic fibers, and the handling of high-purity chemicals. In the electrical industry, they are utilized in battery components and electronic connectors due to their superior conductivity. The low carbon content of Nickel 201 makes it a preferred choice in high-temperature environments, helping to prevent embrittlement. Common forged components include flanges, valves, shafts, rings, and fittings that are used in corrosive or thermally demanding systems.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
