Neil Metals, based in Kolkata, India, is a reliable manufacturer and supplier of MP35N Bars and Rods, providing high-performance alloys that are built to withstand extreme conditions. Renowned for their durability and resistance to corrosion, the MP35N products from Neil Metals are crafted to uphold the highest standards of quality, precision, and mechanical performance. With state-of-the-art infrastructure and rigorous quality control measures, the company caters to various industries, including aerospace, medical, marine, and chemical processing. Neil Metals is committed to ensuring a consistent supply, precise dimensions, and complete customer satisfaction, establishing itself as a trusted provider of MP35N bars and rods in both local and global markets.
MP35N Bars and Rods are a multiphase alloy made up of roughly 35% cobalt, 35% nickel, 20% chromium, and 10% molybdenum. This unique blend offers exceptional corrosion resistance, impressive tensile strength that surpasses 2068 MPa, and remarkable resistance to stress corrosion cracking and hydrogen embrittlement. The alloy maintains its mechanical properties even in extreme temperatures and harsh environments. MP35N can be enhanced through work hardening and aging, resulting in high fatigue strength, good ductility, and biocompatibility, making it ideal for specialized and critical applications.
| Standards : | ASTM F562 / ASME SF562 |
| Thickness : | Range from .008″ to .0125″ |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form : | Round Bar, Wire |
| Grades | HA 190 / HA 1925 / HA 195 / HE 390 / HE 3925 / HE 395 / HE 397 |
|
Cr |
20 nom |
|
Ni |
35 nom |
|
Mo |
10 nom |
|
Co |
35 nom |
| Material | Condtion | Ultimate Tensile Strength ksi | 0.2 % Yield Strength ksi | Elongation % | Reduction of Area % | Hardness HRC |
| MP35N AMS 5844 | Solution Heat Treated and Work Strengthened | 255 | 225 | 12 | 50 | 45 |
| MP35N AMS 5845 | Solution Heat Treated and Work Strengthened and Aged | 260 | 230 | 8 | 35 | 38 min |
| PHYSICAL PROPERTIES | ||||||
|---|---|---|---|---|---|---|
| Density | Electrical conductivity (% IACS) | Thermal conductivity (BTU-in/hr-ft²-°F) | Specific heat capacity | Thermal expansion (1/°F) | Melting Point (°F) | |
| 0..305 | 1.67 | 78 | 0.12 | 0.00000711 | 2510 | |
Yes, MP35N bars can be recycled after use. As a high-performance alloy, it can be melted down and reused to produce new components without significant loss of quality.
MP35N rods are sized based on their diameter and length, typically ranging from 1/16" to 6" diameter and custom lengths, depending on application requirements and manufacturing specifications.
MP35N rods are available in various sizes, typically ranging from 1/8" to 8" in diameter. Common finishes include cold drawn, hot rolled, and annealed for enhanced machinability and surface quality.
MP35N Bars and Rods find their place in demanding applications that require exceptional strength, corrosion resistance, and longevity. In the aerospace sector, they are utilized in fasteners, springs, and structural components. The medical field depends on MP35N for surgical instruments, orthopedic implants, and cardiovascular devices, thanks to its non-magnetic and biocompatible characteristics. Additionally, it is employed in marine and chemical processing equipment, where resistance to saltwater and aggressive chemicals is essential. In the energy industry, MP35N is used in downhole tools and high-pressure components due to its strength and resistance to hydrogen embrittlement.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
