Dimensions : ASTM, ASME and API
Specifications : ASTM B 164, B 865, ASME SB 164, SB 865
Grade : Monel 400 (UNS No. N04400)
Size : 6 mm to 120 mm.
Form : Square
Length : Random, Fix & Cut Length
Finish : Bright, Polish & Black
Neil Metals is a well-respected manufacturer and supplier of top-notch Monel Square Bars, located in Kolkata, India. They specialize in high-performance nickel-copper alloys, crafting Monel bars that are built to endure harsh and corrosive environments. Renowned for their impressive strength, corrosion resistance, and durability, Monel Square Bars are perfect for marine, chemical, and industrial uses. With a strong commitment to international standards and a customer-centric approach, Neil Metals guarantees consistent quality, timely deliveries, and tailored solutions. Supported by advanced facilities and a talented team, the company is a trusted partner for Monel alloy products across various industries.
Monel Square Bars are mainly made up of about 63% Nickel and 28–34% Copper, along with trace amounts of Iron, Manganese, Carbon, and Silicon. This distinctive nickel-copper alloy provides outstanding resistance to seawater, acids, and alkalis. In terms of mechanical properties, Monel boasts a tensile strength of roughly 550–620 MPa and a yield strength of around 240–345 MPa, depending on how it’s processed. It also maintains excellent ductility and toughness across a wide temperature range. Monel keeps its strength even in sub-zero conditions and resists stress corrosion cracking, making it ideal for demanding and corrosive applications.
Dimensions : ASTM, ASME and API
Specifications : ASTM B 164, B 865, ASME SB 164, SB 865
Grade : Monel 400 (UNS No. N04400)
Size : 6 mm to 120 mm.
Form : Square
Length : Random, Fix & Cut Length
Finish : Bright, Polish & Black
| Element | Max | Min |
| Ni | – | 63.0 |
| Fe | 1.0 – 2.5 | – |
| C | 0.3 | – |
| Mn | 2.0 | – |
| Si | 0.5 | – |
| Cu | 28.0 – 34.0 | – |
| Al | 0.50 | – |
| S | 0.02 | – |
| Element | Monel |
| Density | 8.8 g/cm3 |
| Melting Point | 1350 °C (2460 °F) |
| Tensile Strength | Psi – 80,000 , MPa – 550 |
| Yield Strength (0.2%Offset) | Psi – 35,000 , MPa – 240 |
| Elongation | 40 % |
Monel Square Bars find extensive use in industries that need materials with high strength and resistance to corrosive environments. In the marine industry, they are utilized for propeller shafts, pump components, and seawater valves because of their remarkable resistance to saltwater corrosion. The chemical and petrochemical sectors rely on Monel bars for processing equipment, heat exchangers, and tanks that handle acids and alkalis. They are also used in aerospace components, oil and gas applications, and electrical connectors. Thanks to their durability, Monel Square Bars are a go-to choice for a variety of demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
