Neil Metals, located in Kolkata, India, has built a solid reputation as a reliable manufacturer and supplier of top-notch Inconel 792 Bars and Rods, specifically designed to meet the demanding needs of high-temperature industries. With years of experience in metallurgy, the company prides itself on delivering precision-engineered products that adhere to global standards and cater to customer specifications. Inconel 792 Bars and Rods are particularly prized for their remarkable strength, resistance to oxidation, and thermal stability, even in extreme conditions. Neil Metals serves a variety of sectors, including aerospace, gas turbines, and power generation, ensuring consistent quality, dependable delivery, and technical support for both domestic and international clients in search of durable, high-performance nickel-based superalloys.
Inconel 792 is a nickel-based superalloy primarily made up of Nickel (around 60%), Chromium (12–14%), Aluminum (3–5%), Titanium (approximately 4%), Cobalt (about 10%), along with trace amounts of Molybdenum, Zirconium, and Boron. This alloy boasts excellent creep strength and oxidation resistance at temperatures reaching up to 1000°C. Its mechanical properties include impressive tensile strength (typically exceeding 900 MPa), good fatigue strength, and long-lasting structural stability under thermal stress. The microstructure of the alloy is enhanced with gamma prime (γ’) precipitates, which significantly boost its performance in high-stress environments, especially after undergoing proper heat treatment.
| Specifications | ASTM B116 / ASTM SB116 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | 5 mm to 500 mm |
| Diameter | 0.1 mm to 100 mm |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Length | 100 mm To 3000 mm Long & Above |
| Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Element | Composition (%) |
| Nickel (Ni) | 60.0 – 65.0 |
| Chromium (Cr) | 12.0 – 14.0 |
| Cobalt (Co) | 9.0 – 10.0 |
| Aluminum (Al) | 3.0 – 4.5 |
| Titanium (Ti) | 3.5 – 4.5 |
| Molybdenum (Mo) | 1.5 – 2.5 |
| Tantalum (Ta) | 0.50 – 1.50 |
| Zirconium (Zr) | 0.02 – 0.15 |
| Boron (B) | 0.010 – 0.020 |
| Carbon (C) | 0.12 – 0.20 |
| Silicon (Si) | ≤ 0.50 |
| Manganese (Mn) | ≤ 0.50 |
| Iron (Fe) | ≤ 3.0 |
| Property | Value |
| Tensile Strength | 1000 – 1400 MPa |
| Yield Strength (0.2%) | 800 – 1100 MPa |
| Elongation | 5 – 15% |
| Hardness | 350 – 450 HB |
| Impact Strength | Good at elevated temperatures |
| Property | Value |
| Density | 8.25 g/cm³ |
| Melting Range | 1260 – 1340°C |
| Thermal Conductivity | 11.2 W/m·K at 20°C |
| Specific Heat Capacity | 0.410 J/g·K at 20°C |
| Electrical Resistivity | 1.22 μΩ·m at 20°C |
| Coefficient of Thermal Expansion | 13.3 x 10⁻⁶ /°C (20-1000°C) |
Yes, Inconel 792 bars and rods are designed for high-temperature applications, providing excellent strength, oxidation resistance, and thermal stability, making them ideal for extreme heat environments.
Yes, Inconel 792 bars and rods are recyclable. Their high nickel and chromium content allows them to be efficiently reused in various industries, reducing waste and promoting sustainability.
Inconel 792 bars and rods generally do not require additional corrosion protection coatings due to their inherent resistance to oxidation and corrosion, especially in high-temperature and harsh environments.
Inconel 792 Bars and Rods find extensive application in the aerospace and gas turbine industries for crafting turbine blades, vanes, and other components that operate in high-heat areas, thanks to their exceptional heat and oxidation resistance. They are also utilized in power plants for parts that endure extreme heat and stress, such as combustion chambers and transition ducts. The alloy’s resilience under fluctuating thermal conditions makes it ideal for turbochargers, exhaust systems, and heat shields. Furthermore, Inconel 792 is used in industrial furnaces and other high-temperature processing equipment that demands long-term structural integrity and resistance to creep.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
