Neil Metals, which is headquartered in Kolkata, India, is a reliable producer and supplier of **Incoloy Rectangular Bars**, providing superior nickel-based alloy bars for harsh industrial applications. Durable, resistant to corrosion, and thermally stable, Neil Metals’ Incoloy rectangular bars are specifically suited for usage in high-temperature and harsh chemical service conditions. Manufactured by employing advanced production methods and rigorous quality checks, these rectangular bars are provided with uniform performance and size accuracy. Suppling industries like petrochemicals, marine, heat treatment, and power generation, Neil Metals guarantees its Incoloy rectangular bars conform to international standards of reliability, durability, and long-term operating efficiency.
**Incoloy Rectangular Bars** are supplied in various grades like **Incoloy 800, 800H, 800HT, 825, 925, and 330**, which are formulated with different proportions of **Nickel, Chromium, Iron, Molybdenum, Copper, and Titanium** according to particular industrial requirements. These alloys have high **mechanical strength (up to 700 MPa tensile strength)**, **oxidation resistance**, and **corrosion resistance**—particularly against acids, chloride stress cracking, and scaling at high temperatures. The majority of Incoloy grades also have good weldability and formability, as well as the capacity to sustain structural integrity in oxidizing and reducing conditions.
| Dimensions | BS, DIN, EN, AISI, JIS, ASME, ASTM |
|---|---|
| Rectangular Bars Section | 3.0 – 12.0 milimeter thickness |
| Surface | Bright, Hot Rolled Pickled, Hairline, Cold Drawn, Sand Blasting Finished, Polished |
| Processing | cutting to 650 milimeter |
| Tolerance | H9, K9, H8, H12, K12, H11, H13, K10, K11, H10, or as per need |
| Finish | centreless ground, Cold (bright) drawn, smooth turned, hot rolled, slit rolled edge, peeled, Rough Turned, hot rolled annealed, Polish, Bright, Centreless Ground, Grinding & Black |
| Method | Cold Drawn, Hot Rolled, Cold Rolled Rod, Forged Round Bars |
| Condition | annealed, Hardened & tempered |
| Density | g/cm3 | 7.94 | |
|---|---|---|---|
| lb/in.3 | 0.287 | ||
| Melting Range | °F | 2475 – 2525 | |
| °C | 1357 – 1385 | ||
| Condition & Size | Tensile Strength | Yield Strength (0.2% Offset) | Elongation | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| MPa, min | MPa, min | %, min | %, min | Rockwell, max | |
| Hot worked, as-hot-worked | 550 | 240 | 25 | … | … |
| Cold-worked and hot-worked, annealed | 515 | 205 | 30 | … | … |
**Incoloy Rectangular Bars** find extensive applications in **chemical processing, pollution control systems, marine engineering, oil and gas platforms, pressure vessels, heat exchangers, furnace components**, and **nuclear power systems**. Their **sulfuric, nitric, and phosphoric acid**, as well as **chloride-induced corrosion** resistance, makes them ideal for **severe service environments**. These bars also have the best application in **structural frameworks, brackets, and supports** where high mechanical strength and corrosive resistance are necessary. Incoloy rectangular bars, regardless of whether under high-pressure, high-temperature, or corrosive environments, offer unprecedented reliability and performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
