Neil Metals stands out as a top-notch manufacturer and supplier of high-quality Incoloy Hollow Bars, proudly based in Kolkata, India. With a focus on corrosion-resistant and high-temperature alloys, Neil Metals crafts Incoloy hollow bars that are designed for precision, strength, and reliability. These bars are perfect for applications that require weight reduction and internal machining without sacrificing performance. Thanks to advanced manufacturing techniques, rigorous quality control, and a customer-first mindset, Neil Metals caters to essential industries like chemical processing, power generation, marine, and aerospace. Their Incoloy hollow bars comply with international standards and are trusted for critical applications in challenging environments.
Incoloy Hollow Bars are primarily made up of Nickel (30–45%), Chromium (19–23%), and Iron, with varying amounts of Molybdenum, Copper, Titanium, and Aluminum, depending on the specific grade (like Incoloy 800, 825, or 925). These elements provide outstanding resistance to oxidation, carburization, and corrosion, even in harsh acidic and high-temperature settings. Typically, the bars boast a tensile strength ranging from 550–750 MPa and a yield strength of 220–450 MPa. Incoloy hollow bars retain their structural integrity and mechanical strength under thermal stress, making them ideal for critical structural and process equipment.
| Dimensions | BS, DIN, EN, AISI, JIS, ASME, ASTM |
|---|---|
| Size of Round Bars | Thickness: 2 milimeter-100 milimeter |
| Surface | Bright, Hot Rolled Pickled, Hairline, Cold Drawn, Sand Blasting Finished, Polished |
| Processing | cutting to 650 milimeter |
| Tolerance | H9, K9, H8, H12, K12, H11, H13, K10, K11, H10, or as per need |
| Finish | centreless ground, Cold (bright) drawn, smooth turned, hot rolled, slit rolled edge, peeled, Rough Turned, hot rolled annealed, Polish, Bright, Centreless Ground, Grinding & Black |
| Method | Cold Drawn, Hot Rolled, Cold Rolled Rod, Forged Round Bars |
| Condition | annealed, Hardened & tempered |
| Density | g/cm3 | 7.94 | |
|---|---|---|---|
| lb/in.3 | 0.287 | ||
| Melting Range | °F | 2475 – 2525 | |
| °C | 1357 – 1385 | ||
| Condition & Size | Tensile Strength | Yield Strength (0.2% Offset) | Elongation | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| MPa, min | MPa, min | %, min | %, min | Rockwell, max | |
| Hot worked, as-hot-worked | 550 | 240 | 25 | … | … |
| Cold-worked and hot-worked, annealed | 515 | 205 | 30 | … | … |
| US Bar | Metric | Japanese | Canadian/ASTM | ||||
|---|---|---|---|---|---|---|---|
| Diam. (Inch) | Bar Size | Diam. (mm) | Bar Size | Diameter (mm) | Bar Size | Diameter (mm2) | Bar Size |
| 0.250 | #2 | 5 | 5 | 6 | 6 | 100 | 10M |
| 0.375 | #3 | 5.5 | 5.5 | 10 | 10 | 200 | 15M |
| 0.500 | #4 | 6 | 6 | 13 | 13 | 300 | 20M |
| 0.625 | #5 | 7 | 7 | 16 | 16 | 500 | 25M |
| 0.750 | #6 | 8 | 8 | 19 | 19 | 700 | 30M |
| 0.875 | #7 | 9 | 9 | 22 | 22 | 1000 | 35M |
| 1.000 | #8 | 10 | 10 | 25 | 25 | 1500 | 45M |
| 1.125 | #9 | 11 | 11 | 29 | 29 | 2500 | 55M |
| 1.250 | #10 | 12 | 12 | 32 | 32 | ||
| 1.375 | #11 | 14 | 14 | 35 | 35 | ||
| 1.500 | #12 | 16 | 16 | 38 | 38 | ||
| 1.625 | #13 | 18 | 18 | 41 | 41 | ||
| 1.750 | #14 | 20 | 20 | 44 | 44 | ||
| 1.875 | #15 | 22 | 22 | 48 | 48 | ||
| 2.000 | #16 | 25 | 25 | 51 | 51 | ||
| 2.250 | #18 | 28 | 28 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 | ||||||
Incoloy Hollow Bars find extensive use in industries where high strength, corrosion resistance, and weight efficiency are essential. In chemical and petrochemical facilities, they are utilized in heat exchangers, reactors, and processing lines that handle aggressive media. In the power generation sector, they are employed in boiler tubes, superheaters, and steam lines that endure extreme temperatures. The aerospace and marine industries rely on Incoloy hollow bars for components that need to be lightweight yet durable. They are also used in oil and gas applications, including…
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
