Neil Metals, based in Kolkata, India, stands out as a top manufacturer and supplier of high-quality Incoloy 800H Forgings, designed to excel in high-temperature environments while resisting corrosion. Renowned for their precision, reliability, and durability, our Incoloy 800H Forgings are crafted using cutting-edge forging techniques and rigorous quality checks. These forgings are perfect for tough industrial settings like petrochemical processing, power generation, and heat-treating equipment. With a strong focus on customer satisfaction, Neil Metals provides tailored sizes and shapes to fit specific needs, ensuring consistent quality and prompt service, making us a go-to source for high-performance Incoloy 800H products.
Incoloy 800H Forgings mainly consist of iron (the balance), nickel (30–35%), and chromium (19–23%), along with small amounts of aluminum, titanium, and carbon. This unique blend offers remarkable resistance to oxidation, carburization, and high-temperature corrosion. Compared to Incoloy 800, Incoloy 800H boasts enhanced creep and rupture strength, particularly at temperatures exceeding 600°C (1112°F). The alloy showcases impressive tensile strength (typically 85–95 ksi), solid yield strength, and excellent metallurgical stability even under extended thermal exposure. These characteristics make Incoloy 800H Forgings ideal for pressure vessels, high-heat components, and critical structural applications in corrosive and thermally cycling environments.
Specifications ASTM B564 / ASME SB564, AMS 5766
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | Ni | Fe | Cr | Cu | Ti | Al | C | Mn | S | Si |
| Alloy 800H | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .15-.60 | .15-.60 | .05-.10 max | 1.5 max | .015 max | 1.0 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | Psi – 30,000 , MPa – 205 | 30 – 35 % |
| Density | 0.287 lb/in3 / 7.94 g/cm3 |
| Melting Point | 2475 – 2525 °F/ 1357 – 1385 °C |
| Specific Heat @ 70°F | 0.11 Btu/lb•°F |
| Permeability @ 70°F Annealed | 1.014 (200 Oersted) |
| Curie Temperature | -115 °C/ -175 °F |
| Elastic Modulus | 28.50 X 106 psi |
| Electrical Resistivity @ 70°F | 595 ohm•circ mil/ft |
| Annealling Incoloy 800 | 983 – 1038 °C / 1800 – 1900 °F |
| Annealling Incoloy 800H / Ht | 1147 – 1177°C / 2100 – 2150 °F |
| Quench | Rapid Air / Water |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 800H | N08810 | 1.4958 | Z8NC32-21 | X10NiCrAlTi32-20 | NCF 800H | NA 15(H) | ЭИ670 | XH32T |
Incoloy 800H Forgings find extensive use in high-temperature and high-stress scenarios across various industries. In petrochemical and chemical processing, they’re utilized in reactors, heat exchangers, reformer tubing, and furnace manifolds. Power plants rely on them for superheater and reheater tubing, steam headers, and boiler components, thanks to their durability against thermal fatigue and oxidation. In heat-treating equipment, Incoloy 800H is the go-to choice for its exceptional performance in demanding conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
