Neil Metals, located in Kolkata, India, has built a solid reputation as a manufacturer and supplier of top-notch High Speed Steel M35 Bars. They specialize in providing exceptional tool steel solutions tailored for industrial machining, cutting, and forming tasks. With a strong focus on quality and precision, Neil Metals crafts M35 bars that boast impressive wear resistance, hot hardness, and toughness. Thanks to their advanced production techniques and rigorous quality control, they meet the demands of various industries, including toolmaking, automotive, aerospace, and manufacturing. Neil Metals also offers customized dimensions, quick delivery, and technical support, making them a reliable partner for all high-performance high-speed steel needs.
High Speed Steel M35 Bars are cobalt-alloyed tool steels that contain about 0.90% carbon, 4.8% chromium, 5.0% cobalt, 6.0% tungsten, 2.0% molybdenum, 8.0% vanadium, with the remainder being iron. This unique blend enhances red hardness, allowing the steel to maintain its strength even at high temperatures. M35 showcases a tensile strength ranging from 1000 to 1300 MPa and achieves excellent hardness levels (up to 65–67 HRC) after heat treatment. It offers remarkable wear resistance, edge retention, and toughness, making it perfect for crafting tools that need to withstand intense mechanical and thermal stress in high-speed cutting scenarios.
| ASTM A600 | C | Mn | P | S | Si | Cr | V | Mo | W | Co | ||||||||
| M35 | 0.82 | 0.95 | 0.15 | 0.40 | 0.03 | 0.03 | 0.20 | 0.45 | 3.80 | 4.50 | 1.75 | 2.15 | 4.75 | 5.25 | 5.50 | 6.50 | 4.60 | 5.00 |
| DIN ISO 4957 | C | Mn | P | S | Si | Cr | V | Mo | W | Co | ||||||||
| 1.3243/HS6-5-2-5 | 0.87 | 0.95 | … | 0.40 | 0.03 | 0.03 | … | 0.45 | 3.80 | 4.50 | 1.70 | 2.10 | 4.70 | 5.20 | 5.90 | 6.70 | 4.50 | 5.00 |
| JIS G4403 | C | Mn | P | S | Si | Cr | V | Mo | W | Co | ||||||||
| SKH55 | 0.87 | 0.95 | … | 0.40 | 0.03 | 0.03 | … | 0.45 | 3.80 | 4.50 | 1.70 | 2.10 | 4.70 | 5.20 | 5.90 | 6.70 | 4.50 | 5.00 |
| Temperature °C / °F | |||||||
| 20 / 70 | 400 / 750 | 600 / 1110 | |||||
| Density | Kg/m³ lbs/in³ | 8150 .294 | 8050 .290 | 7990 .228 | |||
| Modulus of Elasticity | kN/mm³² psi | 230 34 · 10 6 | 205 31 · 10 6 | 184 27 · 10 6 | |||
| Coefficient of Thermanl expansion from 20°C / 70°F | per °C per °F | – | 11.6 · 10-6 6.4 · 10-6 | 11.9 · 10-6 6.6 · 10-6 | |||
| Thermal Conductivity | W/m °C Btu/sq. ft. h °F/in. | 24 166 | 28 194 | 27 187 | |||
| Specific Heat | J/kg °C Btu/lb °F | 420 0.10 | 510 0.12 | 600 0.14 | |||
| Country | USA | German | Japan |
| Standard | ASTM A600 | DIN EN ISO 4957 | JIS G4403 |
| Grades | M35 | 1.3243/HS6-5-2-5 | SKH55 |
| Thermal properties | Metric | Imperial |
| CTE, linear (@21 – 399°C / 69.8 – 750°F) | 11.4 μm/m°C | 6.33 μin/in°F |
| CTE, linear (@21 – 593°C /69.8 – 1100°F) | 11.5 μm/m°C | 6.39 μin/in°F |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Yes, High-Speed Steel M35 can be welded, but it requires careful control of heat and preheating. Post-weld heat treatment is often necessary to restore its hardness and performance.
Yes, High-Speed Steel M35 bars can be customized in terms of dimensions, shape, and surface finish. Machining and heat treatment processes can also be tailored to meet specific performance requirements.
High Speed Steel M35 Bars find extensive use in applications that demand extreme hardness, wear resistance, and thermal stability. In the toolmaking sector, they are commonly used to create drill bits, reamers, taps, end mills, gear cutters, and saw blades. The aerospace and automotive industries rely on M35 bars for precision cutting tools and form tools that operate at high speeds and temperatures. They are also well-suited for cold work punches, dies, and other components where edge retention and hot hardness are essential. The cobalt content in M35 makes it particularly effective for machining hard metals and alloys, ensuring a long tool life and dependable performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
