Neil Metals, located in Kolkata, India, has built a solid reputation as a manufacturer and supplier of top-notch Copper Nickel Bright Bars. These bars are celebrated for their outstanding corrosion resistance, durability, and smooth surface finish. With a strong focus on quality and precision, Neil Metals offers these bars in various grades, including 70/30 and 90/10, to meet the needs of industries that demand high performance. Manufactured to comply with international standards, these bright bars can be customized in size and finish. Neil Metals proudly serves key sectors such as marine, offshore, chemical processing, and power generation, providing reliable solutions along with timely delivery and exceptional customer service.
Copper Nickel Bright Bars are primarily made up of copper (60–90%) and nickel (10–30%), often with added iron and manganese to boost their strength and corrosion resistance. They excel in resisting seawater and biofouling. In terms of mechanical properties, these bars offer tensile strength between 400–600 MPa, yield strength around 150–250 MPa, and elongation of up to 35%. They also maintain good thermal conductivity, workability, and strength even under pressure and high temperatures, making them perfect for tough and corrosive environments in both marine and industrial applications.
Specification : EN, DIN, JIS, ASTM, BS, ASME, AISI
Standard Specification : ASTM B111 / ASME SB111
Size : 15NB to 150NB IN
Diameter : 3.17mm to 350mm diameter
Length : 100 mm to 3000 mm Long & Above
Tolerance : H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements
Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Form : Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc
Surface : Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Hairline
Condition : Cold Drawnd Pulished Cold Drawn Centreless Ground & Polished
| Grade | Mn | Cu | Pb | Fe | Ni | Zn |
|---|---|---|---|---|---|---|
| 90/10 | 1.0 max | 88.6 min | 0.5 max | 1.8 max | 9-11 max | 1 max |
| 70/30 | 1 max | 65.0 min | 0.5 max | 0.4-1.0 | 29-33 | 1 max |
| Grade | Melting point | Density | Tensilestrength | Elongation | Yieldstrength(0.2%Offset) |
|---|---|---|---|---|---|
| 90/10 | 2260°F | 8.8g/cm3 | 50000 PSi | 30% | 20000PSi |
| 70/30 | 2260°F | 0.323 lb/in3 at 68°F | 50000 PSi | 30% | 20000PSi |
| Grade | UNS | Werkstoff Nr. |
| 90/10 | C70600 | 2.0872 |
| 70/30 | C71500 | 2.0882 |
| Bar Diameter (mm) | Weight (kg/m) |
|---|---|
| 6 | 0.22 |
| 8 | 0.39 |
| 10 | 0.62 |
| 12 | 0.89 |
| 16 | 1.58 |
| 20 | 2.47 |
| 25 | 3.85 |
| 32 | 6.31 |
| 40 | 9.86 |
| 45 | 12.5 |
| 50 | 15.4 |
| 60 | 22.2 |
| 65 | 26.0 |
| 75 | 34.7 |
| 90 | 49.9 |
| 100 | 61.6 |
Yes, Copper Nickel bright bars are highly customizable in terms of dimensions, lengths, and surface finishes to meet specific industry requirements, providing tailored solutions for various applications and projects.
These Copper Nickel Bright Bars find extensive use in industries that require exceptional corrosion resistance and strength in challenging conditions. In marine and shipbuilding, they are utilized for condenser tubes, pump components, seawater piping, and heat exchangers. The offshore oil and gas sector employs them in risers, manifolds, and platform structures. In power plants, they are essential for cooling systems and condensers. Additionally, these bars are used in chemical processing, desalination plants, and defense equipment. Their remarkable formability, durability, and resistance to biofouling make Copper Nickel Bright Bars ideal for critical applications that demand long-lasting performance in aggressive environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
