Neil Metals, located in Kolkata, India, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Carbon Steel Hex Bars and Rods. With a commitment to precision manufacturing and strict adherence to international standards, Neil Metals delivers hexagonal bars and rods that boast impressive strength, durability, and machinability. These products come in a variety of grades and sizes, tailored to meet the diverse demands of industries like automotive, construction, machinery, and fabrication. By prioritizing quality, timely delivery, and customer satisfaction, Neil Metals guarantees dependable solutions for structural components, fasteners, and mechanical parts that require robust performance and long-lasting service.
Typically, Carbon Steel Hex Bars and Rods have a carbon content ranging from 0.10% to 0.60%, along with manganese (0.60–1.65%) and trace elements such as silicon, sulfur, and phosphorus. This blend results in a well-rounded mix of tensile strength, ductility, and wear resistance. The mechanical properties usually feature tensile strength between 450–850 MPa, yield strength from 250–600 MPa, and elongation of 10–25%, depending on the specific grade. These bars are known for their good weldability, toughness, and machinability, making them ideal for a wide range of manufacturing and engineering applications.
Carbon Steel Hex Bar Range: 3.17 MM TO 350 MM DIA
Steel Low Carbon Hexagon Rod Size: 2mm ~ 100mm
High CS Hollow Hex Bar Thickness : 50 – 6000 mm Long
Carbon Steel Hexagonal Bright Bar Technique :
Black Carbon Steel Hot Rolled Hex Bar Benefits :
| Grade | Mn | Si | C | Cr | P | Ni | S | Mo | Cu | fe | Vanadium (max) | Niobium (max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| EN19 | .50 to .80 | .10 to .35 | .35 to .45 | .90 to 1.40 | .04 | to | .04 | .20 to .40 | ||||
| EN-9 | .50 to .80 | .05 to .35 | .50 to .60 | .040 MAX | .040 MAX | |||||||
| A36 | 1.03% | .28% | .25 – .290 % | .04% | .05% | .20% | 98.00% | |||||
| A105 | .60-1.05 | .10- .35 | .35 | .3 | .035 | .4 | .04 | .12 | .4 | .08 | .02 | |
| A353 | .50 to 1.00 | .10 to .35 | .10 to .20 | .75 to 1.25 | Max .040 | 1.00 to 1.50 | Max .040 | .08 to .15 | ||||
| EN 47 | .50- .80% | .50% max | .45- .55% | .80-1.20% | .06% max | .06% max | ||||||
| EN 45 | .50 to .90% | 0/1 to .35 | .75 to .90% | .04% Max | .04% Max | |||||||
| EN24 | .45 – .70 | .10 – .35 | .36 – .44 | 1.00 – 1.40 | Max .035 | 1.30 – 1.70 | Max .040 | .20 – .35 | ||||
| Grade | Yield Strength, | Tensile Strength, | Elongation at Break (in 50 mm) | Bulk Modulus (typical for steel) | Modulus of Elasticity | HBW | Poissons Ratio | Fatigue strength coefficient, of (Mpa) | Shear Modulus | Impacting Energy | Reduction of area, min: |
|---|---|---|---|---|---|---|---|---|---|---|---|
| a36 | 250 MPa | 400 – 550 MPa | 23.00% | 140 GPa | 200 GPa | 0.26 | 79.3 GPa | ||||
| 36300 psi | 58000 – 79800 psi | 23.00% | 20300 ksi | 29000 ksi | 0.26 | 11500 ksi | |||||
| EN45 | 35 (241) | 80 (551) | 40% | 204 Gpa | 948 | ≥63 | |||||
| EN19 | ≥930 Mpa | ≥1080 Mpa | ≥12 | 217 | ≥45 | ||||||
| 105 | 36,000 psi [250 MPa] | 70,000 psi (485 MPa] | 187 | 30% min | |||||||
| EN8 | ≥210 | ≥380 | ≥25 | ≤111HB | ≥50 |
Yes, carbon steel hex bars can attract magnets because carbon steel is a ferromagnetic material, meaning it has magnetic properties and can be magnetized.
Yes, carbon steel hex bar can be recycled after use. It is highly recyclable and can be melted down and reused in the production of new steel products without losing quality.
Carbon steel hex bars and rods come in various grades, including mild steel, medium carbon steel, and high carbon steel. Common types include ASTM A36, A105, A529, A992, and 1045.
Carbon Steel Hex Bars and Rods find extensive use across various industries thanks to their versatile shape and mechanical properties. In the automotive and machinery sectors, they serve as shafts, bolts, gears, and fasteners that demand strength and durability. The construction and fabrication industries utilize them for structural components, supports, and frames. Additionally, hex bars are favored in the production of tools, dies, and agricultural equipment. Their distinctive hexagonal shape allows for easy machining and secure fitting, making them perfect for mechanical assemblies, precision engineering, and heavy-duty applications where reliability and performance are crucial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
