Neil Metals, located in Kolkata, India, stands out as a top manufacturer and supplier of Carbon Steel A105 Bars and Rods. They provide high-quality forged carbon steel products that are essential for various industrial applications. Renowned for their strength, toughness, and affordability, the A105 bars and rods from Neil Metals are meticulously engineered to align with global standards and cater to specific customer needs. With a strong focus on quality, prompt delivery, and technical assistance, the company supports a range of industries, including oil & gas, petrochemicals, power generation, and general engineering. Neil Metals has earned a reputation for offering reliable carbon steel solutions that excel in high-pressure and high-temperature settings.
The composition of Carbon Steel A105 Bars and Rods includes carbon (up to 0.25%), manganese (0.60–1.05%), phosphorus (maximum 0.035%), sulfur (maximum 0.040%), and silicon (0.10–0.35%), with the remainder being iron. These bars boast impressive mechanical properties, featuring a tensile strength ranging from 485 to 655 MPa, a yield strength of about 250 MPa, and commendable elongation and impact resistance. A105 carbon steel is also suitable for heat treatment processes like normalizing and quenching, which boost its strength and durability. Its well-balanced composition guarantees toughness, workability, and structural integrity across a variety of operating conditions.
| International Specifications | ASTM A105, ASME SA105 |
| Manufacturing Process | Forged/Hot Rolled/Cold Drawn/Peeled |
| Equivalent grades | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SA105 Round Bar Dimensions | 3.0 – 50.8 mm, Over 50.8 – 300mm |
| ASTM A105 Rectangular Bars | 6.35 x 12.7mm,6.35 x 25.4mm,12.7 x 25.4mm |
| A105 Carbon Steel Hex Bars | AF5.8mm–17mm |
| Carbon Steel A105 Square Bar | AF2mm – 14mm, AF6.35mm,9.5mm,12.7mm, 15.98mm,19.0mm, 25.4mm |
| Carbon Steel A105 Flat Bars | 1/2” to 10” in the thickness range of 2mm to 150mm, |
| Finishes Available | Bright, Polish & Black |
| Length | 1meter to 6 Meters |
| Shapes | Hexagonal, Rounds, Square, Hex, Rectangular, Hollow, Flat, |
| Forms of A105 Bars in Stock: | Billet, Ingot, Forging Etc. |
| Carbon Steel | C | Si | Mn | P | S | Cr |
| A105 | 0.35 | 0.10-0.35 | 0.60-1.05 | 0.035 | 0.040 | 0.30 |
| Tensile Strength (N/mm2) | Elongation % | HB max |
| 485 | 22 | 187 |
| SIZE IN INCHES | ROUND | SQUARE | OCTAGON | HEXAGON | SIZE IN INCHES | ROUND | SQUARE | OCTAGON | HEXAGON |
| 1/16 | .010 | .013 | .011 | .012 | 11/16 | 1.262 | 1.607 | 1.333 | 1.392 |
| 5/64 | .017 | .022 | .018 | .019 | 45/64 | 1.320 | 1.681 | 1.394 | 1.456 |
| 3/32 | .023 | .029 | .024 | .025 | 23/32 | 1.380 | 1.756 | 1.487 | 1.521 |
| 7/64 | .031 | .039 | .033 | .034 | 47/64 | 1.440 | 1.834 | 1.521 | 1.588 |
| 1/8 | .042 | .053 | .044 | .046 | 3/4 | 1.502 | 1.913 | 1.586 | 1.656 |
| 9/64 | .053 | .067 | .056 | .058 | 25/32 | 1.630 | 2.075 | 1.721 | 1.797 |
| 5/32 | .065 | .083 | .069 | .072 | 13/16 | 1.763 | 2.245 | 1.862 | 1.944 |
| 11/64 | .079 | .100 | .083 | .087 | 27/32 | 1.901 | 2.421 | 2.008 | 2.096 |
| 3/16 | .094 | .120 | .099 | .104 | 7/8 | 2.045 | 2.603 | 2.159 | 2.254 |
| 13/64 | .110 | .140 | .116 | .121 | 29/32 | 2.193 | 2.792 | 2.316 | 2.418 |
| 7/32 | .128 | .163 | .135 | .141 | 15/16 | 2.347 | 2.988 | 2.479 | 2.588 |
| 15/64 | .147 | .187 | .155 | .162 | 31/32 | 2.506 | 3.191 | 2.646 | 2.763 |
| 1/4 | .167 | .213 | .176 | .184 | 1 | 2.670 | 3.400 | 2.820 | 2.945 |
| 17/64 | .188 | .240 | .199 | .207 | 1-1/16 | 3.015 | 3.838 | 3.183 | 3.324 |
| 9/32 | .211 | .269 | .223 | .233 | 1-1/8 | 3.380 | 4.303 | 3.569 | 3.727 |
| 19/64 | .235 | .300 | .248 | .259 | 1-3/16 | 3.766 | 4.795 | 3.977 | 4.152 |
| 5/16 | .261 | .332 | .275 | .288 | 1-1/4 | 4.172 | 5.313 | 4.407 | 4.601 |
| 21/64 | .288 | .360 | .304 | .318 | 1-5/16 | 4.600 | 5.857 | 4.858 | 5.072 |
| 11/32 | .316 | .402 | .334 | .348 | 1-3/8 | 5.049 | 6.428 | 5.332 | 5.567 |
| 23/64 | .345 | .439 | .364 | .381 | 1-7/16 | 5.518 | 7.026 | 5.827 | 6.085 |
| 3/8 | .376 | .478 | .397 | .414 | 1-1/2 | 6.008 | 7.650 | 6.345 | 6.625 |
| 25/64 | .408 | .519 | .431 | .450 | 1-9/16 | 6.519 | 8.301 | 6.885 | 7.189 |
| 13/32 | .441 | .561 | .466 | .486 | 1-5/8 | 7.051 | 8.978 | 7.446 | 7.775 |
| 27/64 | .475 | .605 | .502 | .524 | 1-11/16 | 7.604 | 9.682 | 8.030 | 8.385 |
| 7/16 | .511 | .651 | .540 | .564 | 1-3/4 | 8.178 | 10.41 | 8.634 | 9.018 |
| 29/64 | .548 | .698 | .579 | .604 | 1-13/16 | 8.773 | 11.17 | 9.265 | 9.673 |
| 15/32 | .587 | .747 | .620 | .647 | 1-7/8 | 9.388 | 11.95 | 9.911 | 10.35 |
| 31/64 | .627 | .798 | .662 | .692 | 1-15/16 | 10.02 | 12.76 | 10.58 | 11.05 |
| 1/2 | .668 | .850 | .705 | .736 | 2 | 10.68 | 13.60 | 11.28 | 11.78 |
| 33/64 | .710 | .904 | .750 | .783 | 2-1/16 | 11.36 | 14.46 | 11.99 | 12.53 |
| 17/32 | .754 | .960 | .796 | .831 | 2-1/8 | 12.06 | 15.35 | 12.73 | 13.30 |
| 35/64 | .799 | 1.017 | .844 | .881 | 2-3/16 | 12.78 | 16.27 | 13.49 | 14.09 |
| 9/16 | .845 | 1.076 | .892 | .932 | 2-1/4 | 13.52 | 17.21 | 14.27 | 14.91 |
| 37/64 | .893 | 1.136 | .943 | .985 | 2-5/16 | 14.28 | 18.18 | 15.08 | 15.75 |
| 19/32 | .941 | 1.199 | .994 | 1.038 | 2-3/8 | 15.06 | 19.18 | 15.91 | 16.61 |
| 39/64 | .992 | 1.263 | 1.048 | 1.094 | 2-7/16 | 15.87 | 20.20 | 16.75 | 17.49 |
| 5/8 | 1.043 | 1.328 | 1.102 | 1.150 | 2-1/2 | 16.69 | 21.25 | 17.62 | 18.40 |
| 41/64 | 1.096 | 1.395 | 1.207 | 1.209 | 2-9/16 | 17.53 | 22.33 | 18.52 | 19.34 |
| 21/32 | 1.150 | 1.464 | 1.214 | 1.268 | 2-5/8 | 18.40 | 23.43 | 19.43 | 20.29 |
| 43/64 | 1.205 | 1.535 | 1.272 | 1.329 | 2-11/16 | 19.29 | 24.56 | 20.37 | 21.27 |
Our Carbon Steel A105 Bars and Rods offer exceptional strength, durability, and corrosion resistance. They exhibit a tensile strength of 485 MPa (min), yield strength of 250 MPa (min), and elongation of 22% (min), making them ideal for high-pressure and high-temperature applications.
These bars and rods are extensively used in the oil and gas, petrochemical, power generation, marine, and construction industries. They are essential for flanges, fittings, valves, heat exchangers, and pressure vessels.
Carbon Steel A105 Bars and Rods find extensive use in industries that demand high strength and durability, especially under high-pressure and high-temperature scenarios. In the oil & gas and petrochemical fields, they are commonly utilized in flanges, fittings, valves, and pressure vessels. The power generation sector incorporates them into boiler components and heat exchangers. Additionally, they play a role in general engineering, construction, shipbuilding, and the fabrication of industrial machinery and heavy equipment. Thanks to their excellent machinability and weldability, A105 carbon steel bars and rods deliver long-lasting performance and reliability in critical structural and mechanical applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
