Neil Metals, based in Kolkata, India, stands out as a top manufacturer and supplier of Aluminium 7075 bars and rods. They specialize in high-strength, aerospace-grade aluminium products that cater to industries demanding exceptional mechanical performance and durability. Renowned for their precision engineering and commitment to global standards, Neil Metals offers Aluminium 7075 in various customized sizes and tempers, serving key sectors like aerospace, defense, automotive, and engineering. With state-of-the-art production facilities, a strong focus on customer satisfaction, and rigorous quality control, Neil Metals has earned a reputation as a reliable partner for delivering efficient aluminium solutions both in India and around the globe.
Aluminium 7075 bars and rods are primarily made up of aluminium (about 87%), with zinc (5.6–6.1%), magnesium (2.1–2.5%), and copper (1.2–1.6%), along with trace amounts of chromium, iron, and silicon. This heat-treatable alloy boasts remarkable strength, featuring a tensile strength of 510–580 MPa, yield strength of 430–500 MPa, and elongation of 5–11% depending on the temper. It excels in fatigue resistance and offers decent machinability, although its corrosion resistance is somewhat lower, making it perfect for structural applications in high-stress environments.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight % | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Each | Total |
| Minimum | 1.20 | 2.10 | 0.18 | 5.10 | ||||||
| Maximum | 0.40 | 0.50 | 2.00 | 0.30 | 2.90 | 0.28 | 6.10 | 0.20 | 0.05 | 0.15 |
| Temper | Tensile | Hardness | ||||
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6, T651 | 83 | 572 | 73 | 503 | 11 | 150 |
| T73, T7351 | 73 | 503 | 63 | 434 | 13 | N/A |
| UNS | EN | DIN,WNr | JIS | AFNOR | ISO | BS | GOST |
| A97075 | ENAW-AlZn5.5MgCu EN AW-7075 | 3.4365 AlZnMgCu1.5 | 7075 | 7075 A-Z5GU | AlZn6MgCu | 7075 L95 L96 | V95 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 7075 bar is commonly used for structural applications due to its high strength, excellent corrosion resistance, and lightweight properties, making it suitable for aerospace, automotive, and military structural components.
Aluminium 7075 rods are sized based on their diameter and length. Diameters typically range from 1/8" to 12", and lengths vary from 3' to 20', depending on specific customer requirements.
To maintain Aluminium 7075 bar, regularly clean it with mild soap and water to remove dirt. Avoid harsh chemicals, and store it in a dry, cool environment to prevent corrosion and damage.
Aluminium 7075 bars and rods find extensive use in aerospace applications, including aircraft fittings, wing spars, and fuselage frames, thanks to their outstanding strength-to-weight ratio. In the defense sector, they are utilized for weapon components, armored structures, and tactical gear. The automotive and motorsport industries rely on 7075 for performance-critical parts like suspension systems and engine mounts. Additionally, it’s employed in marine applications, sporting goods (like bicycle frames and archery equipment), and industrial machinery where strength and fatigue resistance are crucial. Despite its lower corrosion resistance, Aluminium 7075 remains a preferred choice for precision, high-load structural applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
