Neil Metals, located in Kolkata, India, has earned a solid reputation as a reliable manufacturer and supplier of Aluminium 6063 bars and rods. Their aluminium products are celebrated for their impressive corrosion resistance, strong mechanical properties, and exceptional surface finish. With a focus on versatile aluminium alloys, Neil Metals serves various industries, including construction, automotive, and electrical sectors. Thanks to their advanced manufacturing capabilities and unwavering commitment to quality, their Aluminium 6063 bars and rods consistently meet international standards, offering customers dependable, durable, and customizable solutions for a wide array of applications, both domestically and internationally.
Aluminium 6063 bars and rods are primarily made up of aluminium (about 97%), with alloying elements like magnesium (0.45–0.9%), silicon (0.2–0.6%), and small amounts of iron, copper, manganese, and chromium. This heat-treatable alloy boasts a tensile strength ranging from 170 to 230 MPa, a yield strength of 130 to 190 MPa, and an elongation of 8 to 12%, depending on the temper. Renowned for its excellent corrosion resistance, moderate strength, and good weldability, Aluminium 6063 also shines in anodizing properties, making it a top choice for architectural and structural applications.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Cu | Si | Fe | Mn | Mg | Zn | Cr | Ti | Other Each | Others Total | Al |
| .10 (max) | .20/.60 | .35 (max) | .10 (max) | .45/.90 | .10 (max) | .10 (max) | .10 (max) | .05 | .015 | Remainder |
| Tensile Strength (psi) | Yield Strength (psi) | Elongation (% in 2″) | Brinell Hardness |
| 27,000 | 21,000 | 12 | 60 |
| UNS | EN | DIN, WNR | ISO | BS (OLD) | USA | WNR |
| A96063 | AW-AlMg0,7Si EN AW-6063 | AlMgSi0.5 | AlMg0,7Si | HE9 | AA6063 | 3.32206 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 6063 rods can be customized in size and length according to specific requirements. Manufacturers offer flexibility in dimensions to meet various application needs and industry standards.
To maintain Aluminium 6063 bars, clean regularly with mild soap and water, avoid harsh chemicals, and inspect for scratches or corrosion. For enhanced longevity, apply a protective coating if needed.
Yes, Aluminium 6063 bars are highly recyclable. Aluminium can be reused indefinitely without losing quality, making it an eco-friendly choice. Recycling helps conserve resources and reduces energy consumption in production.
You’ll find Aluminium 6063 bars and rods commonly used in architectural projects like window frames, door frames, and curtain walls, thanks to their sleek finish and resistance to corrosion. In the automotive sector, they play a crucial role in lightweight components, helping to reduce vehicle weight and enhance fuel efficiency. The electrical industry also takes advantage of 6063 for cable trays and busbars, benefiting from its conductivity and durability. Additionally, it finds applications in general engineering, furniture manufacturing, and marine uses where moderate strength and good corrosion resistance are essential. Its versatility and outstanding surface finish make Aluminium 6063 a go-to choice across numerous industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
