Neil Metals, based in Kolkata, India, has built a solid reputation as a reliable manufacturer and supplier of Aluminium 5082 bars and rods. These products are celebrated for their high strength and resistance to corrosion, making them perfect for tough environments. With a commitment to precision and consistent quality, Neil Metals caters to various industries, including marine, transportation, and structural engineering. Their Aluminium 5082 bars and rods are crafted using cutting-edge manufacturing techniques and meet international standards. Neil Metals is dedicated to providing dependable, durable, and efficient solutions tailored to the unique needs of clients both locally and globally.
Aluminium 5082 bars and rods are primarily made up of aluminium (about 95%), along with magnesium (4.0–4.9%) and manganese (0.2–0.7%), plus trace amounts of chromium and iron. This alloy boasts a tensile strength ranging from 275 to 350 MPa, a yield strength of 125 to 250 MPa, and an elongation of 10 to 20%, depending on the temper. Notably, Aluminium 5082 is non-heat-treatable, providing excellent corrosion resistance, particularly in marine and chemical settings, while also offering good weldability, moderate strength, and superb workability for forming and machining.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| GRADE | Al | Cr | Cu | Fe | Mg | Mn | Si | Ti | Zn | Residuals |
| 5082 | 95.2 to 98.3% | 0.25% max | 0.1% max | 0.5% max | 0.6 to 1.2% | 0.4% to 1.0% | 0.7 to 1.3% | 0.1% max | 0.2% max | 0.15% max |
| Density | Melting Point | Modulus of Elasticity | Electrical Resistivity | Thermal Conductivity | Thermal Expansion | Specific Heat |
| Value | 2700 kg/m3 | 555°C | 70 GPa | 0.038×10-6 Ω.m | 180 W/m.K | 24×10-6 /K |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg4,5 | AG4,5 | 3.3345 | A95082 | AlMg4,5 | 5082 | AlMg4,5 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Maintain Aluminum 5082 bars by regularly cleaning with mild soap and water to prevent dirt buildup. Avoid harsh chemicals, use non-abrasive tools, and protect against corrosion by storing in dry conditions.
Yes, Aluminium 5082 bars are recyclable. Like most aluminum alloys, they can be melted down and reused without significant loss of properties, making them an environmentally sustainable material.
Yes, Aluminium 5082 rods can be customized in size and length. Manufacturers often offer custom dimensions to meet specific requirements for industrial, construction, or engineering applications.
In the marine industry, Aluminium 5082 bars and rods are extensively used for shipbuilding, hulls, and deck structures due to their remarkable resistance to saltwater corrosion. In transportation, they find applications in fuel tanks, vehicle panels, and trailers where both strength and lightweight characteristics are crucial. The chemical and food processing sectors also rely on them for storage tanks and pressure vessels, thanks to their formability and chemical resistance. Additionally, Aluminium 5082 is ideal for architectural and structural uses, providing durability and reliability in both indoor and outdoor settings.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
