Neil Metals, based in Kolkata, India, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Aluminium 2017 Bars and Rods. They provide dependable solutions for industries that prioritize strength, machinability, and resistance to corrosion. Renowned for their outstanding performance in structural and engineering applications, Aluminium 2017 products from Neil Metals are crafted with precision and adhere to international standards. The company caters to various sectors, including aerospace, automotive, defense, and general engineering, offering customized dimensions and prompt deliveries. Neil Metals is dedicated to delivering durable, high-performance aluminum solutions tailored to meet the unique needs of its global customers.
Aluminium 2017 Bars and Rods mainly consist of 3.5–4.5% copper, 0.4–1.0% manganese, 0.2–0.8% magnesium, along with trace amounts of iron, silicon, and zinc, with aluminum making up the rest. These bars boast impressive mechanical properties, featuring a tensile strength of about 430–520 MPa and a yield strength close to 275 MPa. Aluminium 2017 also showcases good machinability, fair corrosion resistance, and excellent workability when heat-treated. It’s often utilized in scenarios where high strength and machinability take precedence over corrosion resistance, particularly in the aerospace and structural engineering fields.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others Each | Other Total |
| 2017 | Rem | 0.20-0.8 | 0.7 max | 3.5-4.5 | 0.40-1.0 | 0.40-0.8 | 0.10 max | 0.25 max | 0.15 max | 0.05 max | 0.15 max |
| Material | Condition | Tensile Strength (N/mm²) min | Yield Strength | Elongation in 4D % | ||
| ksi | Mpa | ksi | Mpa | |||
| 2017 | 2017-T4 Bar | 55 | 379 | 32 | 221 | 12 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 2017 | A92017 | 3.1325 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 2017 can be welded, but it requires careful control due to its high strength and susceptibility to cracking. Specialized welding techniques like TIG or MIG are recommended.
To maintain Aluminium 2017, regularly clean with mild detergent and water, avoid abrasive materials, store in a dry environment, and prevent exposure to corrosive substances to preserve its strength and appearance.
Aluminium 2017 rods are typically sized by diameter and length. Common diameters range from 1/8 inch to several inches, while lengths can vary from a few feet to custom sizes based on needs.
Aluminium 2017 Bars and Rods find extensive use in applications that demand high strength, precision, and good machinability. In the aerospace sector, they are used for aircraft structures, wing frames, and engine components. The automotive industry employs them for gears, shafts, and precision-machined parts. In defense and ordnance, Aluminium 2017 is favored for structural and ballistic components due to its impressive mechanical strength. Additionally, it’s utilized in marine hardware, construction, and general engineering applications where a blend of formability and durability is crucial. However, it’s typically reserved for environments with limited corrosion exposure.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
