Neil Metals, based in Kolkata, India, stands out as a trusted manufacturer and supplier of Aluminium 1060 bars and rods. They pride themselves on delivering top-notch products designed for industries that demand exceptional electrical conductivity, corrosion resistance, and high workability. With a keen eye on precision, durability, and the unique needs of their customers, Neil Metals provides Aluminium 1060 bars and rods suitable for a variety of applications in electrical, chemical, and general industrial sectors. Supported by state-of-the-art infrastructure and a strong commitment to quality, they guarantee timely deliveries and reliable performance, making them a go-to choice for aluminium solutions both locally and internationally.
Aluminium 1060 bars and rods contain at least 99.6% aluminium, with small amounts of iron (≤0.35%), silicon (≤0.25%), and trace elements like copper, manganese, and zinc. This alloy isn’t heat-treatable, but it offers a tensile strength ranging from 60 to 120 MPa, a yield strength of 30 to 80 MPa, and elongation of up to 35%, depending on the temper. Renowned for its excellent thermal and electrical conductivity, remarkable corrosion resistance, and superior formability, Aluminium 1060 is particularly well-suited for cold-working and forging processes.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Aluminium 1060 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.15 – 0.20 | 0.10 – 0.15 | 0.01 – 0.03 | 0.01 – 0.03 | 0.01 – 0.05 | 0.01 – 0.03 | 0.020 – 0.030 | 99.60 |
| Mechanical Properties – Al 1060 | |||||||||||||||||||
| Alloy | Temper | UTS(Mpa) | % Elongation | ||||||||||||||||
| Min | Max | 0.5 mm -0.8 mm | 0.81 mm – 1.30 mm | 1.30 mm – above | |||||||||||||||
| 1060 | O | 55 | 75 | 25 | 25 | 30 | |||||||||||||
| H12 | 75 | 110 | 6 | 6 | 7 | ||||||||||||||
| H14 | 90 | 120 | 5 | 5 | 6 | ||||||||||||||
| H16 | 95 | 130 | 4 | 4 | 4 | ||||||||||||||
| H18 | 130 | — | 3 | 3 | 3 | ||||||||||||||
| STANDARD | UNS | DIN |
| Aluminium 1060 | A91060 | – |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 1060 bars are corrosion-resistant. Due to its high purity, this alloy naturally forms a protective oxide layer on its surface, which helps resist corrosion from moisture and environmental factors.
Yes, Aluminium 1060 rods can be customized in size and length. Manufacturers typically offer customization to meet specific requirements for various industrial applications, ensuring precise dimensions and optimal performance.
Yes, Aluminium 1060 bars can be recycled after use. Aluminium is highly recyclable without losing its properties, making it an eco-friendly material that can be reused multiple times in various applications.
These Aluminium 1060 bars and rods find extensive use in industries that prioritize high conductivity and corrosion resistance while minimizing mechanical stress. In the electrical sector, they’re utilized in busbars, conductors, and transformer windings. The chemical processing industry employs them for storage tanks, piping, and reaction vessels, thanks to their resistance to chemical corrosion. In construction, they’re used in cladding, window frames, and roofing components. The food processing and packaging sectors also depend on Aluminium 1060 for its hygienic, non-reactive properties. Their lightweight nature and malleability make them perfect for applications that require easy fabrication, excellent electrical performance, and long-lasting durability.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
