Neil Metals, located in Kolkata, India, has made a name for itself as a reliable manufacturer and supplier of Aluminium 1050 bars and rods. These high-purity aluminium products are celebrated for their outstanding electrical conductivity, resistance to corrosion, and excellent formability. With cutting-edge production capabilities and a commitment to precision, Neil Metals ensures that their Aluminium 1050 bars and rods meet international quality standards, serving a variety of industries including electrical, chemical, construction, and food processing. Their dedication to customer satisfaction, timely delivery, and consistent product performance has established Neil Metals as a trusted provider of Aluminium 1050 solutions in both local and global markets.
Aluminium 1050 bars and rods consist of at least 99.5% pure aluminium, with small amounts of iron (≤0.4%), silicon (≤0.25%), and trace elements like copper, manganese, and zinc. This alloy, which cannot be heat-treated, boasts a tensile strength ranging from 60 to 100 MPa, a yield strength of 25 to 80 MPa, and an elongation of up to 35%, depending on the temper. Known for its superb conductivity, high resistance to corrosion, and good workability, Aluminium 1050 is perfect for cold-working, bending, and forging in low-strength applications.
| Bar Wire Standard | ASTM B221, B211, B565, B316, AMS 4121 2014 |
| Bar Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Rectangular Size | 33 x 30mm to 295 x 1066mm |
| Bars Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Bar Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Tempers | Tempers range from dead soft annealed to ultra spring temper |
| Rolled Flat Bars Condition | Hardened & tempered, annealed |
| Cold Rolled Bar Technique | Stainless Steel Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Rounds Bar Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Grade | C | Mn | Si | Cu | Fe | Zn |
| 1050 | 0.05 max | 0.1 max | 0.30 max | 0-0.05 | 0-0.4 | 0-0.07 |
| UTS (Mpa) | Yield Strength (Mpa) | Elongation |
| 95 | 20 Min | 23 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS |
| EN AW-1050 A | 3.0255 | A91050 | S1B |
Yes, Aluminium 1050 bars are corrosion-resistant due to their high aluminum content (99.5%). They offer excellent resistance to corrosion in atmospheric conditions and chemical environments, making them suitable for various applications.
Yes, Aluminium 1050 rods can be customized in size and length based on specific requirements. Manufacturers often offer tailored dimensions to meet diverse industrial and commercial needs.
To maintain a Stainless Aluminum 1050 bar, clean it regularly with a soft cloth and mild detergent, avoid abrasive cleaners, store in a dry environment, and inspect for corrosion or damage.
These Aluminium 1050 bars and rods find their way into various applications where corrosion resistance, conductivity, and ease of fabrication are crucial. In the electrical industry, they are the go-to choice for bus bars, transformer windings, and electrical enclosures due to their impressive electrical conductivity. The chemical and food sectors utilize them for equipment like storage tanks, vessels, and kitchen components, thanks to their non-toxic and non-reactive properties. In construction, Aluminium 1050 is often used for decorative trims, signage, and roofing. Its lightweight nature and excellent formability also make it a popular choice for lighting, reflectors, and HVAC components across a wide range of industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
