Neil Metals, located in Kolkata, India, has built a solid reputation as a reliable manufacturer and supplier of top-notch Alloy Steel F9 Bars and Rods. Known for their precision engineering and durability, Neil Metals meets a wide range of industrial needs by offering strong steel solutions. Their Alloy Steel F9 Bars and Rods are produced using cutting-edge technology to adhere to strict standards, guaranteeing outstanding performance and dependability. With a strong focus on quality and prompt delivery, Neil Metals has become a go-to partner for clients looking for exceptional alloy steel products in the competitive landscape of Kolkata and beyond.
Alloy Steel F9 Bars and Rods are primarily made of iron mixed with about 9% chromium, which boosts their corrosion resistance and strength. They also contain controlled amounts of carbon, manganese, and sometimes molybdenum to enhance hardness, tensile strength, and toughness. These bars showcase impressive mechanical properties, including high tensile strength, good fatigue resistance, and excellent wear resistance. Their well-balanced composition allows them to endure tough operating conditions while keeping their structural integrity under heavy loads and fluctuating temperatures.
| Steel Round Bars type | F9 Round bars Die Steel Bar |
|---|---|
| Spring steel | 65Mn, 1566, 60Si2Mn, 9260, etc. |
| Standards | ASTM A689, JIS G4801, DIN 17221, GB/T 18254, ASTM A295, JIS G4805, etc. |
| Cold heading steel | ML25, ML35, etc. |
| Alloy structural steel | 40CrNiMo, SAE4330, 42CrMo, 15Cr2Ni2, 40CrNi2Mo, 35CrMoV,12Cr1MoV, ASTM4130, SCM420, 40CrV, etc. |
| Bearing steel | GCr15, SAE52100, GCr15SiMn, 100CrMnSi6-4, SJU2, etc. |
| Available Material Grade | 42CrMo4/SCM440/AISI 4140/DIN 1.7225, 4130 / 1.7218, 4140 / 1.7225, 4340 / 1.6582, 5140 / 1.7035, 8620 / 1.6523, EN19 / EN24H13 alloy steel round bar, 42 Crmo4 Alloy Steel Round Bar, AISI 4140 alloy steel round bar , 42CrMo4 alloy steel rods
|
| Military steel | 20Cr2Ni4A, 18Cr2Ni4WA, 23CrNiMo7-4-7, etc. |
| F9 Round bars Diameter | 5mm-500mm (Customized size is acceptable) |
| F9 Round bars Length | 1m-9m or according to the customer’s requirement. |
| F9 Round bars Range | Range – 3.17mm to 350mm dia |
| F9 Round bars Technique | Forged/Hot Rolled/Cold Drawn/Peeled |
| F9 Round bars Surface | bright round bar, pickled round bar, black round bar |
| F9 Round bars Type | Round bar, rod, square bar, flat bar, hexagon bar, angle bar, channel bar, threaded bar |
| Package Details | Standard seaworthy package(wooden boxes package, pvc package, or other package) |
| Other processing service | Hot dipped Galvanized, pre-galvanized, Color painting,coated, cutting, bending,punching |
| Test Certificate | Mill Test Certificate as per EN 10204 / 3.1B |
| Grade | C | Mn | Si | P | S | Cr | Mo |
| Alloy Steel F9 | 0.15 max | 0.3-0.6 | 0.5-1 | 0.03 | 0.03 | 8-10 | 0.9-1.1 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 380 | 585 | 20 % |
|
SHAPE |
POUNDS PER FOOT |
|---|---|
|
Round |
D2 x 2.67 |
|
Hexagon |
D2 x 2.945 |
|
Square |
D2 x 3.4 |
|
Flat |
Thickness (in.) x Width (in.) x 3.4 |
Alloy Steel F9 Bars and Rods are mainly used in high-temperature applications like steam turbines, aerospace components, and power plants due to their strength and heat resistance.
Alloy Steel F9 offers excellent creep strength, high tensile strength, and resistance to thermal fatigue, making it ideal for high-pressure environments.
These Alloy Steel F9 Bars and Rods find extensive use in manufacturing components that demand high strength and corrosion resistance. They’re crucial in automotive parts, machinery shafts, fasteners, and structural applications. Their ability to resist wear and deformation makes them perfect for tools and dies in the metalworking industry. Additionally, these bars are utilized in oil and gas pipelines, aerospace, and construction sectors, where durability and reliability under stress are essential. Neil Metals ensures that these bars meet industry standards for performance and longevity across various applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
