Neil Metals is a reliable maker and supplier of Alloy Steel AISI 4140 Rods and Bars, based in Kolkata, India. Concentrating on quality, accuracy, and performance, Neil Metals supplies heat-treated and mechanically improved 4140 alloy steel bars and rods for critical engineering uses. The bars and rods are famous for their superior strength, toughness, and fatigue resistance. Made through high-end forging and machining, Neil Metals has impeccable dimensional accuracy and surface finish. Used across automobile, oil & gas, mining, and general engineering industries, the company provides custom size and specifications to match stringent industrial requirements.
AISI 4140 is a chromium-molybdenum low-alloy steel with a general composition of 0.38–0.43% carbon, 0.75–1.00% chromium, 0.15–0.25% molybdenum, and 0.75–1.00% manganese. This alloy provides a perfect blend of strength, toughness, and wear resistance. Some of the mechanical properties in the heat-treated (normalized and tempered) condition are tensile strength of 655–1080 MPa, yield strength of 415–930 MPa, and elongation of 20–25%. AISI 4140 Bars and Rods undergo good heat treatment (annealing, quenching, and tempering) and machining. Neil Metals offers these products in several rounds, hexes, and flats that can be applied for both structural and high-performance purposes.
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | : | 5 mm To 500 mm |
| Diameter | : | 0.1 mm to 100 mm |
| Length | : | 100 mm To 3000 mm Long & Above |
| Finish | : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Tolerance | : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Form | : | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
| Grade | C | Mn | Si | P | S | Fe | Mo | Ni | Cr |
| AISI / SAE 4140 | 0.38-0.43 | 0.75-1.00 | 0.20-0.35 | 0.035 max | 0.035 MAX | – | – | 0.15-0,25 | 0.80-1.10 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.85 g/cm3 | 1432 ℃ | 560 | 460 | 21.50% |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | EN |
| AISI / SAE 4140 | 1.7225 | G41400 | SCM 440 | BS 708M40 | 1.7223 |
AISI 4140 Bars and Rods are used on a large scale in industries that demand higher strength and fatigue properties. Some of the general applications are crankshafts, axles, gears, spindles, bolts, tool holders, shafts, and hydraulic equipment components. They are employed in the oil & gas sector for drill collars, tool joints, and other downhole tools. The automotive and aeronautical industries use 4140 for load-carrying parts because it is tough and impact resistant. It can also be used for heavy-duty industrial machinery, molds, and dies. AISI 4140’s hardness, strength, and hardenability make it an ideal option for high-stress applications in the mechanical sector.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Neil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kolkata, India
