Kolkata-based Neil Metals is a trusted manufacturer and supplier of Stainless Steel 316L Round Bars and Rods, providing high-quality products for a variety of industrial uses. Renowned for accuracy and strength, Neil Metals offers corrosion-resistant applications that are international quality. Their Stainless Steel 316L rods and bars are extensively utilized in numerous industries on account of their superior mechanical strength and exceptional resistance to corrosive surroundings. With a commitment to quality assurance, prompt delivery, and customer satisfaction, Neil Metals is an established name in the stainless steel market.
Stainless Steel 316L Round Bars and Rods contain 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and minimum carbon content (up to 0.03%), with the remainder as iron. The low-carbon grade improves resistance to intergranular corrosion, particularly post-welding. 316L has a mechanically delivered tensile strength of approximately 485 MPa, yield strength of 170 MPa, and elongation of 40%. The introduction of molybdenum enhances pitting and crevice corrosion resistance in chloride environments. These are complemented by great toughness and weldability, making 316L suitable for applications involving utmost importance in hostile as well as wet environments.
| Grade | Stainless Steel 316L (UNS S31603) |
|---|---|
| Specification | ASTM A276/ A479, ASME SA276/SA479 |
| Round bar size | Outside Diameter in the range of 4mm to 500mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Condition | Hardened & tempered, annealed |
| Technique | 316 Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Processing | Bar cutting to 650mm |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316L | 0.3 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 16 – 18 | 2 – 3 | 10 – 14 | 0.10 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
|
Type |
SIZES (mm) |
SIZES (Inches) |
ISO Tolerance |
|---|---|---|---|
|
Cold Drawn and Polish |
3.00 – 75.00 |
1/8″ – 3.00″ |
h8-h9-h10-h11 |
|
Cold Drawn and Ground |
10.00 – 75.00 |
5/6″ – 2.50″ |
h8-h9-h10-h11 |
|
Peeled and Polished |
40.00 – 150.00 |
1.50″ – 6.00″ |
h11, h11-DIN 1013 |
|
Peeled and Ground |
20.00 – 50.00 |
3/4″ – 2.00″ |
h9-h10-h11 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐032 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
| Round Bar Grade | Dimensions |
|---|---|
| Stainless Steel Round Bar 316L | 1/2 inch – 12 |
| Flat bar size | 18 meter |
| Square bar size | 1-2 inch |
| Round bar size | 1-2 inch,3-4 inch,2-3 inch |
| Hex Bar size | 0-1 inch,3-4 inch |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Neil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kolkata, India
